In Example 18.8 , we analyzed a parallel-plate capacitor (plate area $L \times L$ with $L=0.10 \mu \mathrm{m}$ and $a$ plate separation of $10 \mathrm{nm}$ ) as might be found in an integrated circuit (RAM chip), but we omitted the dielectric that would usually be found between the plates. This dielectric is composed of $\mathrm{SiO}_{2}$ and has a dielectric constant close to that of glass. What is the capacitance of the RAM capacitor in Example 18.8 when it is filled with $\mathrm{SiO}_{2} ?$

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Parallel-Plate Capacitor

A parallel-plate capacitor consists of two conductive plates separated by a small distance. It stores electric charge and energy in the electric field generated between the plates. The geometry of the plates (area and separation) is key to determining its capacitance, making it a fundamental design in circuit analysis.

Capacitance Calculation

The capacitance of a capacitor is a measure of its ability to store charge per unit voltage. For a parallel-plate capacitor, the capacitance is calculated using the formula C = ???A/d, where A is the area of the plates, d is the separation between them, ?? is the permittivity of free space, and ? is the dielectric constant of the material between the plates.

Dielectric Materials and Dielectric Constant

Dielectric materials are insulating substances placed between the plates of a capacitor to increase its capacitance. The dielectric constant (?) is a dimensionless number that indicates how much the presence of the dielectric increases the capacitor’s ability to store charge compared to a vacuum. Incorporating a dielectric material enhances the overall performance of the capacitor by reducing the effective electric field and increasing the stored energy.
