In Fig. $12-45,$ a thin horizontal bar $A B$ of negligible weight and length $L$ is hinged to a vertical wall at $A$ and supported at $B$ by a thin wire $B C$ that makes an angle $\theta$ with the horizontal. A block of weight $W$ can be moved anywhere along the bar; its position is defined by the distance $x$ from the wall to its center of mass. As a function of $x,$ find (a) the tension in the wire, and the (b) horizontal and (c) vertical components of the force on the bar from the hinge at $A .$

In Fig. $12-45,$ a thin horizontal bar $A B$ of negligible weight and length $L$ is hinged to a vertical wall at $A$ and supported at $B$
by a thin wire $B C$ that makes an angle $\theta$ with the horizontal. A
block of weight $W$ can be moved anywhere along the bar; its position is defined by the distance $x$ from the wall to its center of
mass. As a function of $x,$ find (a) the tension in the wire, and the
(b) horizontal and (c) vertical components of the force on the bar
from the hinge at $A .$

Key Concepts

Force Decomposition

Force decomposition is the process of breaking a force vector into its components, typically along mutually perpendicular axes such as horizontal and vertical. This is critical in statics problems to apply the conditions of equilibrium separately in different directions, allowing for the systematic determination of unknown forces.

Moment (Torque) Equilibrium

Moment equilibrium involves taking moments (or torques) about a chosen pivot point to balance the rotational effects of forces. In many statics problems, taking moments about a particular point helps eliminate unknown forces from the equations, making it easier to solve for other unknowns in the system.

Tension in the Support Cable

Tension in the support cable is the force transmitted along the cable that helps maintain equilibrium by counteracting applied forces and moments. Analyzing the tension often involves relating it to the geometry of the system, such as the angle at which the cable is oriented, and incorporating it into the equilibrium equations.

Static Equilibrium

Static equilibrium refers to the state of a system where the sum of all forces and the sum of all moments (torques) acting on the system are zero. This fundamental concept allows the analysis of structures and mechanical systems by ensuring that, under equilibrium, there is no net motion or rotation, and it is critical when determining unknown forces or moments in a system.

Free-Body Diagram

A free-body diagram is a simplified representation of a system or component where all the forces, moments, and reactions are isolated and depicted as vectors. This tool is essential for visualizing the problem, identifying all acting forces, and formulating the equations of equilibrium in order to solve for unknown quantities such as forces or tensions.

Hinge Reaction Forces

Hinge reaction forces are the forces exerted by a fixed support or hinge to maintain equilibrium in a structure. These forces typically have both horizontal and vertical components, and their determination is crucial for understanding how the structure interacts with its supports and ensuring that the overall system satisfies the equilibrium conditions.
