In Fig. 24.9 a, let C1=9.0 μF, C2=4.0 μF, and Va b=36 V . Suppose the charged capacitors are d

step 1 Everybody, so we need to find how much does the energy of the system decrease from this? Okay, s

In Fig. 24.9 a, let C1=9.0 μF, C2=4.0 μF, and Va b=36 V ....

In Fig. $24.9 \mathrm{a},$ let $C_{1}=9.0 \mu \mathrm{F}, \quad C_{2}=4.0 \mu \mathrm{F},$ and $V_{a b}=36 \mathrm{V} .$ Suppose the charged capacitors are disconnected from the source and from each each other, and then reconnected to each other with plates of opposite sign together. By how much does the energy of the system decrease?

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Energy Dissipation During Reconfiguration

Connecting charged capacitors can lead to a decrease in the total stored energy, with the excess energy typically dissipated as heat or electromagnetic radiation during the transient process. This happens because the final state of the system after reconnection generally has a lower energy than the sum of the initial energies, illustrating that not all stored energy is conserved in the form of electric potential energy.

Capacitor Energy Storage

This concept refers to the way capacitors store energy in an electric field, quantified by the equation U = ½CV². The stored energy depends on both the capacitance and the voltage across the capacitor. Understanding this relationship is crucial for determining how energy changes when capacitors are reconfigured in a circuit.

Charge Redistribution and Conservation

When capacitors that have been charged separately are connected together, especially with opposite polarity connections, charge redistributes between them. The law of conservation of charge ensures that the total charge remains unchanged, even though the voltage across each capacitor may change due to the redistribution. This principle is key to analyzing the subsequent voltage and energy distribution in the system.
