In Fig. $6-50,$ block 1 of mass $m_{1}=2.0 \mathrm{kg}$ and block 2 of mass $m_{2}=3.0 \mathrm{kg}$ are connected by a string of negligible mass and are initially held in place. Block 2 is on a frictionless surface tilted at $\theta=30^{\circ} .$ The coefficient of kinetic friction between block 1 and the horizontal surface is $0.25 .$ The pulley has negligible mass and friction. Once they are released, the blocks move. What then is the tension in the string?

Key Concepts

Tension in a String

Tension is the force transmitted through a string, rope, or cable when forces are applied at both ends. In an ideal system with a light, inextensible string and frictionless pulleys, the tension is uniform throughout the string, linking the dynamics of the connected objects and forming a crucial component in the equations of motion.

Newton's Second Law

Newton's second law states that the net force acting on an object is equal to the mass of the object multiplied by its acceleration. This principle is crucial for setting up the equations of motion for each mass in a connected system, enabling the determination of unknown quantities such as acceleration and tension in the string.

Free-Body Diagrams

A free-body diagram is a schematic representation that isolates a body and shows all forces acting on it. This graphical tool is essential for visualizing and identifying all forces—including gravitational, frictional, normal, and tension forces—acting on each object, which is a critical step in solving dynamics problems.

Kinetic Friction

Kinetic friction is the resistive force that opposes the relative motion of surfaces sliding against one another. It is characterized by a coefficient of kinetic friction and depends directly on the normal force, playing a key role in problems where surfaces are in motion, as it affects the net force and, consequently, the acceleration of the body.

Inclined Plane Analysis

Inclined plane analysis involves decomposing the gravitational force into components parallel and perpendicular to the surface of the incline. This technique is fundamental when dealing with objects on slopes, as it allows for the accurate application of Newton’s laws by properly accounting for the effective forces driving or resisting the motion along the incline.

Assumptions of Massless and Frictionless Pulleys

Assuming that a pulley is massless and frictionless simplifies the analysis of a connected system by ensuring that the tension in the string is the same on both sides of the pulley. This assumption removes additional complexities such as energy losses and rotational inertia, making it easier to relate the motions of the connected masses.

Transcript

00:01 So no, here in this problem, static friction coefficient is mentioned.

00:08 So we're not going to deal with the static friction of the static frictional force.

00:12 And we're simply going to only deal with the kinetic frictional force.

00:16 So we can apply newton's second law to the x -axis.

00:19 And we're going to say that the sum of forces in the x -axis for the mass sub -1 would be equal to the mass sub -1 times the acceleration of the system because the masses are both connected here, this would be equal to the tension force minus the kinetic force of friction.

00:40 We can apply then the sum of forces for the second block.

00:45 This would be equal to m sub 2g sine of theta minus the tension force.

00:52 This is equaling m sub 2 times the acceleration of the system.

00:56 We're going to add the two equations and by adding the two equations we find that the acceleration is then equal to m sub 2g sine of theta essentially the tensions cancel out and so this would be minus the kinetic force of friction divided by the sum of the masses m sub 1 plus m sub 2 and at this point we can solve knowing that force of friction kinetic would simply be equal to the coefficient of kinetic friction multiplied by m sub 1g.

01:37 This is given that the sum of forces in the wide direction equals zero for the second mass and this would equal force normal minus m sub 1g.

01:48 So we can essentially assume that the normal force blocks block 1 would be equal to m sub 1g given that the and we know that the kinetic frictional force is equaling the coefficient of kinetic friction times the force normal sub 1.

02:06 Plug that into the formula for the frictional force...
