In Fig. 8-38, the string is L=120 cm long, has a ball attached to one end, and is fixed at its

step 1 We know we're going to use the conservation of mechanical energy. Excuse me. So the mechanical e

In Fig. 8-38, the string is L=120 cm long, has a ball...

In Fig. $8-38$, the string is $L=120 \mathrm{~cm}$ long, has a ball attached to one end, and is fixed at its other end. A fixed peg is at point $P$. Released from rest, the ball swings down until the string catches on the peg; then the ball swings up, around the peg. If the ball is to swing completely around the peg, what value must distance $d$ exceed? (Hint: The ball must still be moving at the top of its swing. Do you see why?)

Key Concepts

Minimum Speed for Complete Circular Motion

In circular motion, especially when the object is at the highest point of the path, there is a minimum speed that must be maintained to ensure that the centripetal force is sufficient, preventing the string or mechanism from going slack. This minimum speed is derived from the balance between gravitational force and the necessary centripetal force to keep the object moving in a complete circle.

Pendulum Dynamics and Transition of Pivot

When a pendulum encounters a change, such as striking a peg which alters the effective pivot point, its dynamics change due to the alteration in the radius of its path. Analyzing this transition involves understanding how energy and forces redistribute in the system as the pendulum shifts to a new center of circular motion, ensuring conditions for continued complete rotation around the new pivot.

Conservation of Mechanical Energy

This concept explains that as an object moves under the influence of gravity, its potential energy is converted into kinetic energy and vice versa. In the context of pendulum motion, the loss of potential energy from a descent is entirely converted into kinetic energy (assuming no friction), which is then used to propel the object along its circular path.

Centripetal Force Requirement

For any object moving in a circular path, a centripetal force is required to keep it in that motion. This force, which can be supplied by gravity, tension, or a combination of forces, must be sufficient at every point along the circular trajectory, particularly at the top of the path where the gravitational force acts to counteract the inward pull.
