In Figure 2-2 why does the photoelectric current not rise vertically to its maximum (saturation)

step 1 Hello. So in this question, we're asked, why does the photoelectric current, this current, does

In Figure 2-2 why does the photoelectric current not rise...

Key Concepts

Photoelectric Effect

The photoelectric effect refers to the emission of electrons from a metal surface when it is exposed to light of sufficient energy. This phenomenon underpins the relationship between incident light and the kinetic energy of the emitted electrons, as described by Einstein’s equation relating energy, frequency, and work function.

Energy Distribution of Emitted Electrons

Electrons are not emitted with a single, uniform kinetic energy but rather with a distribution of kinetic energies. Due to thermal and material effects, even at a given incident light frequency, some electrons have more energy than others. This spread in energy means that as the applied potential is varied, electrons begin to be collected over a range of potentials rather than all at once.

Saturation Current

The saturation current is the maximum current achieved when all emitted electrons are collected by the anode, regardless of their individual kinetic energies. Because the electrons have a range of kinetic energies, the collection of electrons—and thus the current—increases gradually as the potential becomes favorable enough to collect even the slower electrons before finally reaching saturation.

Retarding and Accelerating Potentials

The applied potential difference plays a crucial role in controlling the motion of the emitted electrons. A slightly positive potential relative to the effective stopping potential does not instantly collect all electrons because it only begins to overcome the retarding forces for the lower-energy electrons. As the potential increases, progressively more electrons meet the condition to reach the collector, leading to a gradual increase in photoelectric current.
