Question
In the circuit shown in the figure, the capacitance for each capacitor is $C$. The equivalent capacitance for these three capacitors isa) $\frac{1}{3} C$.d) $\frac{3}{5} C$.b) $\frac{2}{3} C$.e) $C$.c) $\frac{2}{5} C$.f) $\frac{5}{3} C$.
Step 1
Two of these capacitors are in series and the third one is in parallel with the series combination. Show more…
Show all steps
Your feedback will help us improve your experience
Shahab Ullah and 83 other Physics 102 Electricity and Magnetism educators are ready to help you.
Ask a new question
Labs
Want to see this concept in action?
Explore this concept interactively to see how it behaves as you change inputs.
Key Concepts
Recommended Videos
In the circuit shown in the figure, the capacitance for each capacitor is $C$. The equivalent capacitance for these three capacitors is a) $\frac{1}{3} C$ d) $\frac{3}{4} C$ b) $\frac{2}{3} C$ e) $C$ c) $\frac{2}{3} C$ f) $\frac{3}{3} C$
The equivalent capacitance of the combination of three capacitors, each of capacitance $C$ shown in figure between points $A$ and $B$ is (a) $\frac{c}{2}$ (b) $\frac{3 C}{2}$ (c) $\frac{1}{3 C}$ (d) $2 C$
Electrostatics
Round 2
Five identical capacitors, each with capacitance $C$ are connected as shown in the figure. Then the equivalent capacitance between $A$ and $B$ is (a) $\bar{C}$ (b) $5 C$ (c) $C / 5$ (d) $3 C$
