Is the Nyquist theorem true for high-quality single-mode optical fiber or only for copper wire?

Name: Problem 12, Chapter 2: Computer Networks: Global Edition
Uploaded: 2021-09-20T05:35:36-08:00
Duration: 2 min 31 s
Channel: Arpit Gupta
Description: Is the Nyquist theorem true for high-quality single-mode optical fiber or only for copper wire?

step 1 Consider the telecommunication through the optical fiber. Optical fibers are the type of cable w

Is the Nyquist theorem true for high-quality single-mode...

Key Concepts

Bandwidth-Limited Channels

Bandwidth-limited channels are characterized by a finite range of frequencies over which they can effectively transmit signals. Both copper wires and high-quality single-mode optical fibers exhibit bandwidth limitations due to their physical and material properties. While the available bandwidth may vary between different media, the fundamental principle that a limited bandwidth constrains the maximum data rate still applies.

Transmission Medium Characteristics

Different transmission media, such as copper wires and optical fibers, have unique physical properties like attenuation, dispersion, and noise susceptibility. However, these characteristics influence, rather than alter, the basic theoretical limits provided by concepts like the Nyquist theorem. The theorem remains valid for any medium where the channel can be modeled as band-limited, irrespective of whether it is a traditional copper wire or an optical fiber.

Nyquist Theorem

The Nyquist theorem states that in a noiseless, band-limited channel, there is a maximum rate at which symbols can be transmitted without intersymbol interference. This limit is determined by the channel’s bandwidth, asserting that the maximum symbol rate is twice the available bandwidth. It provides a theoretical upper bound on data rates based solely on the channel’s frequency limitations, independent of the specific transmission medium.
