Problem 63 Easy Difficulty

Knowing that the coefficients of friction between the component $I$ and member $B C$ of the mechanism of Prob. 12.62 are $\mathrm{m}_{\mathrm{s}}=0.35$ and $\mathrm{m}_{k}=0.25,$ determine $(a)$ the maximum allowable constant speed $v_{B}$ if the component is not to slide on $B C$ while being transferred, $(b)$ the values of $u$ for which sliding is impending.

Video Answer

Solved by verified expert

Textbook Answer

Official textbook answer

Video by Khoobchandra Agrawal

Numerade Educator

This textbook answer is only visible when subscribed! Please subscribe to view the answer

Related Courses

Physics 101 Mechanics

Vector Mechanics for Engineers: Statics and Dynamics

Chapter 12

Kinetics of Particles: Newton’s Second Law

Discussion

You must be signed in to discuss.

Top Physics 101 Mechanics Educators

Christina Krawiec

Rutgers, The State University of New Jersey

Watch More Solved Questions in Chapter 12

Problem 1

Problem 2

Problem 3

Problem 4

Problem 5

Problem 6

Problem 7

Problem 8

Problem 9

Problem 10

Problem 11

Problem 12

Problem 13

Problem 14

Problem 15

Problem 16

Problem 17

Problem 18

Problem 19

Problem 20

Problem 21

Problem 22

Problem 23

Problem 24

Problem 25

Problem 26

Problem 27

Problem 28

Problem 29

Problem 30

Problem 31

Problem 32

Problem 33

Problem 34

Problem 35

Problem 36

Problem 37

Problem 38

Problem 39

Problem 40

Problem 41

Problem 42

Problem 43

Problem 44

Problem 45

Problem 46

Problem 47

Problem 48

Problem 49

Problem 50

Problem 51

Problem 52

Problem 53

Problem 54

Problem 55

Problem 56

Problem 57

Problem 58

Problem 59

Problem 60

Problem 61

Problem 62

Problem 63

Problem 64

Problem 65

Problem 66

Problem 67

Problem 68

Problem 69

Problem 70

Problem 71

Problem 72

Problem 73

Problem 74

Problem 75

Problem 76

Problem 77

Problem 78

Problem 79

Problem 80

Problem 81

Problem 82

Problem 83

Problem 84

Problem 85

Problem 86

Problem 87

Problem 88

Problem 89

Problem 90

Problem 91

Problem 92

Problem 93

Problem 94

Problem 95

Problem 96

Problem 97

Problem 98

Problem 99

Problem 100

Problem 101

Problem 102

Problem 103

Problem 104

Problem 105

Problem 106

Problem 107

Problem 108

Problem 109

Problem 110

Problem 111

Problem 112

Problem 113

Problem 114

Problem 115

Problem 116

Problem 117

Problem 118

Problem 119

Problem 120

Problem 121

Problem 122

Problem 123

Problem 124

Problem 125

Problem 126

Problem 127

Problem 128

Problem 129

Problem 130

Problem 131

Problem 132

Problem 133

Video Transcript

Hello, friends. Here it is. Given a parallel link mechanism A B C. D is used to transport our component i between manufacturing process at stations E f and G picking it up component I yes, picking up at angle zero degree Onda depositing. So the next station next station at one. Critically it is given that we see all which remains her gentle and link a V and C D rotate at constant rate in our tickle plane. Yeah, if yeah coefficient of friction between the component I on member busy hot um us is 0.35 That is a static friction. Andi Kinetic friction is 1 to 5. Then first part calculate maximum speed off week if component not slide on B c And in second part we have to find the theater. For Pidge, sliding is impending. Let us the starts alway First we will draw the free body diagram off the component I wait off the component acts vertically downward Normal reaction on the friction and having normal force. I am in tow air in this direction and here normal acceleration is we square by route. This is angle Tito. It varies not taking submission off force along X direction. This is considered to be positive. So you may write f It's called Toe. I am a and cause of theater. We can write the mass in terms off. Wait. The weight divided by G Normal acceleration is we square by rope in two cause of theater. See equation one actually me, please. Commission off forces along by direction and minus bait. Toby minus bait Y g by road. Sign off the top. So from ever being question actually, please Normal reaction having developed one minus square off speed at me. Upon ruin to the sign up, Peter. Maximum friction. Maybe us into it so it would be us. Developed one minus square off his speed. Upon ruin to the sign up. Data for component not to slight have must be less than half mix so we can subdue the value here from equation one and two wait. Divided by G square off speed upon root cause off theater Toby Less than us developed one minus We square white G into row. Sign up today. So from ever be question square off velocity Bilby less than Mewes g into rue upon cause off Fotopoulos New us sign opted out se equation tree fuck satisfy Fight the condition off an equality condition off in equality we squared. B max must be less than are equal toe minimum value off um us G into row divided by cause of theater. Pless um, us silent theater, which occurred when cause off the top plus mu s scientific heavy maximum. That's de upon the off theater. Toby, cause of the topless US sign off the top Must be zero. So from here, you may get minus. I know Peter Plus Mu s car sitter Tau zero. So turn off theater, Toby New s on Dhere. Us is given 135 So theater will be 10 in worse off 0.35 So this angle you will get 19.29 degrees. Oh, okay. Come answer apart. A a maximum Bellu off velocity is the square. Max would be U S G into rope upon because of the topless, um, us sign off theater here. Um, us. It's called to 10 off theater so we can write. We square Max Toby G into rope 10 off theater upon cause it er plus 10 theater into science theater. Now substituting the value G is 32.2. Roux is given 10 by 12 ft and 10 off 19.29 upon cause off. 19.29 plus 10 off 19.29 And to sign off. 19.29 on solving it. Maximum speed you will get. Yeah, 2.98 fit per second. No, I answer for a second part B and Tita may very from 90 degree to one. A two degree equation. Third becomes square off. Velocity used the occasion. Third should be less than us G into row upon because off l populus us. Sign off. Alpa here and fight is 1 80 degree by necesito So we have major 19 point tonight. So, Alfa having the value 1 60 point 71 degree substitute develop We have a pending motion. All right, So the left foot Peter Toby 19.29 Degree on go the right. Yeah, for theater, Toby 1 60.7 degree. That's all for it. Thanks for watching it
