Linear light polarized horizontally passes through a quarterwave plate whose fast axis is $\pi / 8$ rad above the horizontal. Use the phasor method to graphically determine the polarization state of the emerging light. [Hint: $\overrightarrow{\mathbf{E}}$ is along the $x$ -axis below the $x^{\prime}$ -axis, and so the phasor $\mathbf{E}_{y}$ starts pointing downward.

Key Concepts

Polarization States

Polarization describes the orientation and temporal evolution of the electric field vector in an electromagnetic wave. It includes states such as linear, circular, and elliptical polarization, and understanding how different optical elements can transform one state into another is central to optics.

Phasor Representation

The phasor method represents sinusoidally varying quantities, such as the components of an electric field, as complex numbers or rotating vectors. This technique simplifies the analysis of phase and amplitude relationships, making it easier to determine how optical devices like wave plates modify the polarization state.

Wave Plates

A wave plate is an optical device that introduces a specific phase delay between two orthogonal components of light. For instance, a quarter-wave plate introduces a ?/2 phase difference between the fast and slow axes, altering the initial polarization state (e.g., converting linearly polarized light into elliptically polarized light).

Coordinate Transformation

When the axes of an optical element like a wave plate are not aligned with the incoming polarization, it is necessary to decompose the incident electric field into components along the wave plate's fast and slow axes. This coordinate transformation is crucial for analyzing how each component is modified and subsequently recombined to yield the final polarization state.
