Match the following: Column-I (a) Stable equilibrium (b) Unstable equilibrium (c) Neutral cquilibrium (d) Most unstable position of body Column-II (p) Potential energy is zero; $\frac{d U}{d r}-0$ (q) Potential energy is minimum i.e., $\frac{d U}{d r}-$ zcro, $\frac{d^{2} U}{d r^{2}}-1 \mathrm{vc}$ (r) Potential energy is maximum $\frac{d U}{d r}-$ zerv,$\frac{d^{2} U}{d r^{2}}--\mathrm{ve}$ (s) $\frac{d^{2} U}{d r^{2}}-0$

Match the following:
Column-I
(a) Stable equilibrium
(b) Unstable equilibrium
(c) Neutral cquilibrium
(d) Most unstable position of body
Column-II
(p) Potential energy is zero; $\frac{d U}{d r}-0$
(q) Potential energy is minimum i.e., $\frac{d U}{d r}-$ zcro, $\frac{d^{2} U}{d r^{2}}-1 \mathrm{vc}$
(r) Potential energy is maximum $\frac{d U}{d r}-$ zerv,$\frac{d^{2} U}{d r^{2}}--\mathrm{ve}$
(s) $\frac{d^{2} U}{d r^{2}}-0$

Key Concepts

Neutral Equilibrium

Neutral equilibrium occurs when a body displaced slightly from its equilibrium position does not experience a net force pushing it back or further away; the potential energy remains nearly constant. This condition often arises when the second derivative of the potential energy function is zero, meaning there is little or no curvature in the energy landscape.

Second Derivative Test

The second derivative test is a mathematical procedure used to determine the curvature of the potential energy function at an equilibrium position. A positive second derivative indicates a local minimum (stable equilibrium), a negative second derivative indicates a local maximum (unstable equilibrium), and a zero value suggests a point of inflection, which is characteristic of neutral equilibrium.

Unstable Equilibrium

An unstable equilibrium is a state where a small displacement leads to forces that further move the body away from the equilibrium position. In potential energy analysis, unstable equilibrium is indicated by a local maximum where the first derivative is zero and the second derivative is negative.

Equilibrium

Equilibrium in mechanics refers to a state in which the net force on a body is zero. In the context of potential energy, an equilibrium position is typically found by determining where the first derivative of the potential energy with respect to position is zero, indicating no net force acting on the body.

Potential Energy Function

The potential energy function describes how energy is stored in a system due to its position or configuration. Analyzing this function along with its derivatives is fundamental in determining the nature of equilibrium points, such as whether they are stable, unstable, or neutral.

Stable Equilibrium

A stable equilibrium is characterized by the fact that a body, when slightly displaced from the equilibrium position, experiences a restoring force that pushes it back towards equilibrium. In terms of potential energy, this corresponds to a local minimum where the first derivative is zero and the second derivative is positive.
