[materials] Castigliano's theorem says the displacement, $\Delta$, under a force $P$ is given by $$ \Delta=\frac{\partial U}{\partial P} $$ where $U$ is the internal strain energy of the body. For the following, find $\Delta$ : a $U=\frac{P^{2} L}{2 A E}$ b $U=\frac{9 P^{2} L^{3}}{96 E I}$

[materials] Castigliano's theorem says the displacement, $\Delta$, under a force $P$ is given by
$$
\Delta=\frac{\partial U}{\partial P}
$$
where $U$ is the internal strain energy of the body. For the following, find $\Delta$ :
a $U=\frac{P^{2} L}{2 A E}$
b $U=\frac{9 P^{2} L^{3}}{96 E I}$

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Castigliano's Theorem

Castigliano's theorem is an energy method used in structural analysis and mechanics of materials. It states that the displacement in the direction of an applied load is equal to the partial derivative of the structure's total strain energy with respect to that load. This theorem is especially useful for determining deflections in statically indeterminate structures, where direct force methods may be challenging.

Strain Energy

Strain energy is the stored energy in a material or structure as it undergoes deformation under load. In elastic materials, this energy is recoverable and expressed as a function of the applied load and the geometry and material properties of the structure. It is fundamental in energy methods and can be used to derive displacements using principles like Castigliano's theorem.

Partial Differentiation

Partial differentiation is a mathematical technique used to differentiate a function with respect to one variable while treating the other variables as constants. In the context of displacement calculation through energy methods, it involves differentiating the total strain energy with respect to a specific load to obtain the corresponding displacement, reflecting how changes in load affect the energy stored in the structure.
