A small-diameter capillary tube made from drawn aluminum is...

$ \mathrm{A}$ small-diameter capillary tube made from drawn aluminum is used in place of an expansion valve in a home refrigerator, The inside diameter is $0.5 \mathrm{mm}$. Calculate the corresponding relative roughness. Comment on whether this tube may be considered "smooth" with regard to fluid flow.

Key Concepts

Relative Roughness

Relative roughness is defined as the ratio of the absolute roughness of the inner surface of a tube to its internal diameter. This nondimensional parameter is crucial in fluid flow analysis, particularly in determining the friction factor for turbulent flows. It helps engineers assess how the microscopic texture of a surface influences the resistance to flow and associated pressure drops.

Surface Roughness of Materials

Surface roughness refers to the average deviations of the surface from the perfectly smooth condition and is dependent on the material and manufacturing process. In the context of drawn aluminum, the working process typically produces a low absolute roughness. When scaled against the small internal diameter of a capillary tube (for example, 0.5 mm), the resulting relative roughness is often very low, indicating that the surface behaves in a 'smooth' manner with respect to fluid flow.

Influence on Friction Factor and Flow Regime

In turbulent flow conditions, the friction factor, which indicates resistance due to flow along the walls, is affected by the wall roughness. A low relative roughness (e.g., on the order of 10^-3 or lower) implies that the pipe can be treated as smooth in many engineering applications, since the roughness has minimal impact on the friction factor. This is important in the design and analysis of fluid systems where precise control of pressure drops is required.
