Measurement indicates that the peak components of the table vibration of Problem 8.4 are a $0.25-\mathrm{mm}$ component at $100 \mathrm{rad} / \mathrm{s}$ and a $0.4-\mathrm{mm}$ component at $150 \mathrm{rad} / \mathrm{s}$. An available isolator has a stiffness of $8 \times 10^4 \mathrm{~N} / \mathrm{m}$ and a damping ratio of 0.1 . Will the acceleration felt by the apparatus exceed $6 \mathrm{~m} / \mathrm{s}^2$ when this isolator is installed?

Key Concepts

Vibration Isolation

Vibration isolation involves using devices such as isolators to decouple sensitive equipment from ground or structural vibrations. The aim is to minimize the transmission of vibratory energy to the equipment, thereby reducing unwanted motion, stress, and potential damage. This concept is fundamental in engineering to ensure that even if the base or support structure vibrates, the apparatus experiences much lower vibration amplitudes.

Natural Frequency

The natural frequency of a system is the frequency at which it will oscillate when disturbed, in the absence of damping or external forces. In the context of isolators, the natural frequency is determined by the stiffness and mass of the system. It is a critical parameter because if the frequency of the external vibration coincides with or is near the natural frequency of the isolated system, resonance can occur, leading to amplified responses.

Transmissibility

Transmissibility is a measure of how much vibration is transferred from the base (or input) to the isolated mass (or output). It is defined as the ratio of the amplitude of the response of the system to the amplitude of the base excitation. The transmissibility of an isolator depends on the excitation frequency relative to the natural frequency, as well as the damping ratio. A high transmissibility indicates that more vibration energy is transmitted to the apparatus, while a low transmissibility indicates effective isolation.

Damping Ratio

The damping ratio is a dimensionless measure that describes how oscillations in a system decay after a disturbance. In vibration isolation, damping plays a crucial role in controlling the amplitude of resonant vibrations and reducing the transmissibility at and near the natural frequency. A higher damping ratio generally leads to a broader frequency range over which the isolator is effective, although it may also slightly increase the transmitted force at very high frequencies.
