Measurements made on a newly installed air-handling system were: $20 \mathrm{r} / \mathrm{s}$ fan speed, $2.4 \mathrm{~m}^3 / \mathrm{s}$ airflow rate, $340 \mathrm{~Pa}$ fan-discharge pressure, and $1.8 \mathrm{~kW}$ supplied to the motor. These measurements were made with an air temperature of $20^{\circ} \mathrm{C}$, and the motor. These measurements were math air at a temperature of $40^{\circ} \mathrm{C}$. If the fan speed remains at $20 \mathrm{r} / \mathrm{s}$, what will be the operating values of $(a)$ airflow rate, $(b)$ static pressure, and $(c)$ power? Ans. (c) $1.685 \mathrm{~kW}$ (GRAPH CANT COPY)
