Multilayer physisorption is often described by the $B E T$ adsorption isotherm $$ \frac{P}{V\left(P^{*}-P\right)}=\frac{1}{c V_{\mathrm{m}}}+\frac{(c-1) P}{V_{\mathrm{m}} c P^{*}} $$ where $P^{*}$ is the vapor pressure of the adsorbate at the temperature of the experiment, $V_{\mathrm{m}}$ is the volume corresponding to a monolayer of coverage on the surface, $V$ is the total volume adsorbed at pressure $P$, and $c$ is a constant. Rewrite the equation for the BET adsorption isotherm in the form $$ \frac{V}{V_{\mathrm{m}}}=f\left(P / P^{*}\right) $$ Plot $V / V_{m}$ versus $P / P^{*}$ for $c=0.1,1.0,10$, and $100 .$ Discuss the shapes of the curves.

Multilayer physisorption is often described by the $B E T$ adsorption isotherm
$$
\frac{P}{V\left(P^{*}-P\right)}=\frac{1}{c V_{\mathrm{m}}}+\frac{(c-1) P}{V_{\mathrm{m}} c P^{*}}
$$
where $P^{*}$ is the vapor pressure of the adsorbate at the temperature of the experiment, $V_{\mathrm{m}}$ is the volume corresponding to a monolayer of coverage on the surface, $V$ is the total volume adsorbed at pressure $P$, and $c$ is a constant. Rewrite the equation for the BET adsorption isotherm in the form
$$
\frac{V}{V_{\mathrm{m}}}=f\left(P / P^{*}\right)
$$
Plot $V / V_{m}$ versus $P / P^{*}$ for $c=0.1,1.0,10$, and $100 .$ Discuss the shapes of the curves.

Key Concepts

Graphical Analysis and Curve Shapes

Plotting V/V? versus P/P* for varying values of c helps visualize how changes in the adsorption energy affect the isotherm shape. The graphical analysis reveals that lower c values produce more gradual increases in adsorbed volume with pressure, while higher c values emphasize a more pronounced increase associated with strong adsorbate-adsorbent interactions. These plots are useful for interpreting experimental data and determining adsorption mechanisms.

Parameter c in the BET Equation

The constant c in the BET equation is related to the heat of adsorption and provides insight into the interaction strength between the adsorbate and the adsorbent. Different values of c can significantly alter the shape of the adsorption isotherm, influencing the curvature and slope of the plot of V/V? versus P/P*. Low values of c tend to indicate weaker interactions resulting in more gradual adsorption, whereas higher values tend to emphasize the formation of the first monolayer more sharply before multilayer adsorption becomes significant.

Dimensionless Variables (P/P* and V/V?)

Rewriting the BET equation in terms of dimensionless variables, such as the ratio of operating pressure to saturation vapor pressure (P/P*) and the ratio of adsorbed volume to monolayer volume (V/V?), normalizes the data. This makes the isotherm more universally applicable and facilitates comparison across different experiments and materials by reducing the dependence on specific units or conditions.

BET Theory

The BET (Brunauer-Emmett-Teller) theory provides a model for multilayer adsorption, extending the monolayer adsorption concept to account for the formation of additional layers. It is one of the most commonly used models for analyzing adsorption data and determining surface area by relating the volume of adsorbate to pressure and temperature via an empirically derived equation.

Adsorption Isotherm

An adsorption isotherm describes how the quantity of a gas or liquid adsorbed on a solid surface varies with pressure at a constant temperature. It is a key tool in surface science for understanding the interaction between adsorbates and adsorbents, revealing information about surface area, pore structure, and adsorption mechanisms.

Monolayer Capacity (V?)

Monolayer capacity refers to the amount of adsorbate required to cover the adsorbent surface completely with a single layer. In the BET model, V? is central because it represents the baseline loading from which multilayer adsorption is calculated. Accurate determination of V? is crucial for subsequent analyses such as surface area estimation.
