On July 29,1949 , the first gas turbine installed in the United States for generating electric power went into service at the Belle Isle station of the Oklahoma Gas and Electric Company. ${ }^{15}$ It had a 15 -stage compressor with an isentropic pressure ratio of 6 to 1 , a 2 -stage turbine with overall entrance and exit temperatures of $1400^{\circ} \mathrm{F}$ and $780^{\circ} \mathrm{F}$, respectively, and the turbine-generator unit was rated at $3500 \mathrm{~kW}$. Assuming a Brayton cold $A S C$, determine a. The isentropic efficiency of the turbine. b. The Brayton cold ASC thermal efficiency of the entire turbine-compressor unit.

On July 29,1949 , the first gas turbine installed in the United States for generating electric power went into service at the Belle Isle station of the Oklahoma Gas and Electric Company. ${ }^{15}$ It had a 15 -stage compressor with an isentropic pressure ratio of 6 to 1 , a 2 -stage turbine with overall entrance and exit temperatures of $1400^{\circ} \mathrm{F}$ and $780^{\circ} \mathrm{F}$, respectively, and the turbine-generator unit was rated at $3500 \mathrm{~kW}$. Assuming a Brayton cold $A S C$, determine
a. The isentropic efficiency of the turbine.
b. The Brayton cold ASC thermal efficiency of the entire turbine-compressor unit.

Key Concepts

Brayton Cycle

The Brayton cycle is the thermodynamic cycle on which gas turbine engines operate. It consists of four main processes: isentropic compression in the compressor, constant-pressure heat addition, isentropic expansion in the turbine, and constant-pressure heat rejection. This cycle is fundamental for analyzing and designing gas turbines, and it provides a framework for calculating performance parameters such as work output and efficiencies under ideal assumptions.

Isentropic Process and Efficiency

An isentropic process is a reversible adiabatic process in which entropy remains constant. The isentropic efficiency of a turbine (or compressor) is a measure of how closely the actual device approximates the ideal isentropic performance. It is defined as the ratio of the actual work output to the ideal work output, and it serves as a key indicator of the performance and losses in the turbine compared to the idealized process.

Cold Air Standard Assumptions

Cold air standard assumptions simplify the analysis of gas turbine cycles by treating the working fluid as an ideal gas with constant specific heats and assuming that all processes take place at a reference (ambient) temperature. This approach makes it easier to calculate performance parameters, such as thermal efficiency, without the complications introduced by variable properties, and is commonly used in preliminary cycle analysis.

Thermal Efficiency

The thermal efficiency of a turbine–compressor unit in a Brayton cycle is the ratio of the net work output of the cycle to the heat input during the combustion process. Under the cold air standard analysis, this efficiency calculation neglects temperature-dependent property variations, thereby providing a simplified method to assess the cycle's overall performance and to compare the ideal cycle performance with actual engine results.
