Question

On the assumption of a conservative system of external forces, prove Hehmholtz's formulae $$ \begin{gathered} \frac{d}{d l}\binom{\mathbf{w}}{\rho} \cdots \frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v} \\ \frac{d^2}{d t^2}\left(\frac{\mathbf{w}}{\rho}\right) \cdots\left(\frac{d}{d l} \frac{\mathbf{w}}{\rho}\right) \cdot \nabla \mathbf{v}+\frac{\mathbf{w}}{\rho} \cdot \frac{d}{d l} \nabla \mathbf{v} . \end{gathered} $$ i ii Taking the curl of both members of (7) Art. 37 we have $$ \dot{d w}: c u r l(w \cdot v) \quad 0 . $$ Expanding the second term by (18) of Art. 8 , and using the formula (1) of this chapter, we may write the result $$ \begin{aligned} 0 & =\frac{d \mathbf{w}}{d t}+\mathbf{w} \operatorname{div} \mathbf{v}-\mathbf{w} \cdot \nabla \mathbf{v} \\ & =\frac{d \mathbf{w}}{d t}-\frac{\mathbf{w}}{\rho} \frac{d \rho}{d t}-\mathbf{w} \cdot \nabla \mathbf{v} \end{aligned} $$ by the equation of continuity. On division by $\rho$ this becomes $$ \frac{d}{d t}\left(\frac{\mathbf{w}}{\rho}\right)=\frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v} $$ By differentiating this we arrive at the second formula.

   On the assumption of a conservative system of external forces, prove Hehmholtz's formulae

$$
\begin{gathered}
\frac{d}{d l}\binom{\mathbf{w}}{\rho} \cdots \frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v} \\
\frac{d^2}{d t^2}\left(\frac{\mathbf{w}}{\rho}\right) \cdots\left(\frac{d}{d l} \frac{\mathbf{w}}{\rho}\right) \cdot \nabla \mathbf{v}+\frac{\mathbf{w}}{\rho} \cdot \frac{d}{d l} \nabla \mathbf{v} .
\end{gathered}
$$

i
ii

Taking the curl of both members of (7) Art. 37 we have

$$
\dot{d w}: c u r l(w \cdot v) \quad 0 .
$$


Expanding the second term by (18) of Art. 8 , and using the formula
(1) of this chapter, we may write the result

$$
\begin{aligned}
0 & =\frac{d \mathbf{w}}{d t}+\mathbf{w} \operatorname{div} \mathbf{v}-\mathbf{w} \cdot \nabla \mathbf{v} \\
& =\frac{d \mathbf{w}}{d t}-\frac{\mathbf{w}}{\rho} \frac{d \rho}{d t}-\mathbf{w} \cdot \nabla \mathbf{v}
\end{aligned}
$$

by the equation of continuity. On division by $\rho$ this becomes

$$
\frac{d}{d t}\left(\frac{\mathbf{w}}{\rho}\right)=\frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v}
$$


By differentiating this we arrive at the second formula.
Show more…
Advanced Vector Analysis with Application to Mathematical Physics
Advanced Vector Analysis with Application to Mathematical Physics
C.E. Weatherburn 1st Edition
Chapter 4, Problem 12 ↓

Instant Answer

verified

Step 1

# Step-by-Step Solution to Helmholtz's Formulae ## Part (i): Proving $\frac{d}{dt}\left(\frac{\mathbf{w}}{\rho}\right) = \frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v}$  Show more…

Show all steps

lock
AceChat toggle button
Close icon
Ace pointing down

Please give Ace some feedback

Your feedback will help us improve your experience

Thumb up icon Thumb down icon
Thanks for your feedback!
Profile picture
On the assumption of a conservative system of external forces, prove Hehmholtz's formulae $$ \begin{gathered} \frac{d}{d l}\binom{\mathbf{w}}{\rho} \cdots \frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v} \\ \frac{d^2}{d t^2}\left(\frac{\mathbf{w}}{\rho}\right) \cdots\left(\frac{d}{d l} \frac{\mathbf{w}}{\rho}\right) \cdot \nabla \mathbf{v}+\frac{\mathbf{w}}{\rho} \cdot \frac{d}{d l} \nabla \mathbf{v} . \end{gathered} $$ i ii Taking the curl of both members of (7) Art. 37 we have $$ \dot{d w}: c u r l(w \cdot v) \quad 0 . $$ Expanding the second term by (18) of Art. 8 , and using the formula (1) of this chapter, we may write the result $$ \begin{aligned} 0 & =\frac{d \mathbf{w}}{d t}+\mathbf{w} \operatorname{div} \mathbf{v}-\mathbf{w} \cdot \nabla \mathbf{v} \\ & =\frac{d \mathbf{w}}{d t}-\frac{\mathbf{w}}{\rho} \frac{d \rho}{d t}-\mathbf{w} \cdot \nabla \mathbf{v} \end{aligned} $$ by the equation of continuity. On division by $\rho$ this becomes $$ \frac{d}{d t}\left(\frac{\mathbf{w}}{\rho}\right)=\frac{\mathbf{w}}{\rho} \cdot \nabla \mathbf{v} $$ By differentiating this we arrive at the second formula.
Close icon
Play audio
Feedback
Powered by NumerAI
*

Labs

-

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

*

Key Concepts

-
Vector Calculus Identities
Vector calculus identities, such as the properties of the curl, divergence, and gradient operators, are essential tools in manipulating the equations of fluid mechanics. These identities allow for the transformation and simplification of complex differential expressions encountered in the derivation of Helmholtz's formulae, making them indispensable for understanding the relationships between various fluid dynamic quantities.
Equation of Continuity
The equation of continuity embodies the principle of mass conservation in a fluid. It relates the temporal change in density to the divergence of the velocity field, ensuring that mass is neither created nor destroyed. In proofs like that of Helmholtz's formulae, the equation of continuity is used to manipulate and simplify expressions involving the density and velocity field, ensuring consistency with mass conservation.
Material Derivative
The material derivative represents the rate of change of a fluid property as it is experienced along the trajectory of a moving fluid particle. It combines both local and convective changes, and is fundamental in formulating the governing equations of fluid motion, including the equations that lead to Helmholtz's formulae. This derivative facilitates the analysis of dynamic quantities like the vorticity as they evolve with the fluid flow.
Conservative Force Field
A conservative force field is one in which the work done by the force on a particle moving between two points depends only on those endpoints and not on the path taken. This property implies that the force can be expressed as the gradient of a potential function, which is crucial for deriving energy conservation laws and the resulting kinematic and dynamic equations in fluid dynamics, such as Helmholtz's formulae.
Vorticity
Vorticity, defined as the curl of the velocity field, quantifies the local rotation within a fluid. It is a central concept in fluid dynamics that helps describe the rotational behavior of fluid elements. In the derivation of Helmholtz's formulae, the evolution of vorticity and its relationship to other flow properties are examined, making its understanding essential to the analysis.

*
