Outline simple geometric derivations of the formulas for $\sin (\alpha+\beta)$ and $\cos (\alpha+\beta)$ in the case in which $\alpha$ and $\beta$ are acute angles, with $\alpha+\beta < 90^{\circ} .$ The exercises rely on the accompanying figures, which are constructed as follows. Begin, in Figure $A,$ with $\alpha=\angle G A D, \beta=\angle H A G,$ and $A H=1$ Then, from $H,$ draw perpendiculars to $\overline{A D}$ and to $\overline{A G},$ as shown in Figure $B .$ Finally, draw $\overline{F E} \perp \overline{B H}$ and $\overline{F C} \perp \overline{A D}$ (FIGURES CAN'T COPY) Formula for $\sin (\alpha+\beta) .$ Supply the reasons or steps behind each statement. (a) $B H=\sin (\alpha+\beta)$ (b) $F H=\sin \beta$ (c) $\angle B H F=\alpha$ (d) $E H=\cos \alpha \sin \beta \quad$ Hint: Use $\triangle E F H$ and the result in part (b). (e) $A F=\cos \beta$ (f) $C F=\sin \alpha \cos \beta$ (g) $\sin (\alpha+\beta)=\sin \alpha \cos \beta+\cos \alpha \sin \beta$ Hint: $\sin (\alpha+\beta)=B H=E H+C F$

Outline simple geometric derivations of the
formulas for $\sin (\alpha+\beta)$ and $\cos (\alpha+\beta)$ in the case in which $\alpha$ and $\beta$ are acute angles, with $\alpha+\beta < 90^{\circ} .$ The exercises rely on the accompanying figures, which are constructed as follows. Begin, in Figure $A,$ with $\alpha=\angle G A D, \beta=\angle H A G,$ and $A H=1$ Then, from $H,$ draw perpendiculars to $\overline{A D}$ and to $\overline{A G},$ as shown in Figure $B .$ Finally, draw $\overline{F E} \perp \overline{B H}$ and $\overline{F C} \perp \overline{A D}$
(FIGURES CAN'T COPY)

Formula for $\sin (\alpha+\beta) .$ Supply the reasons or steps behind each statement.
(a) $B H=\sin (\alpha+\beta)$
(b) $F H=\sin \beta$
(c) $\angle B H F=\alpha$
(d) $E H=\cos \alpha \sin \beta \quad$ Hint: Use $\triangle E F H$ and the result in part (b).
(e) $A F=\cos \beta$
(f) $C F=\sin \alpha \cos \beta$
(g) $\sin (\alpha+\beta)=\sin \alpha \cos \beta+\cos \alpha \sin \beta$
Hint: $\sin (\alpha+\beta)=B H=E H+C F$

Key Concepts

Properties of Similar Triangles

Similar triangles have identical angle measures and proportional side lengths, which makes them a powerful tool in deriving trigonometric identities. By recognizing similar triangles within a geometrically constructed figure, one can set up proportional relationships between corresponding sides, aiding in the decomposition of trigonometric expressions and the derivation of formulas like the angle addition identities.

Geometric Constructions in Trigonometry

Geometric constructions involve drawing auxiliary lines, such as perpendiculars and projections, to create right triangles within a figure. These constructions are used to visually represent and derive relationships among trigonometric functions by translating abstract algebraic identities into concrete geometric terms. They form a bridge between the visual intuition of geometry and the analytical rigour of trigonometry.

Use of Perpendicular Projections

Drawing perpendiculars from points to lines in geometric constructions is a method to decompose segments into parts that directly represent the sine and cosine components of an angle. This technique is instrumental in breaking down the relationships in a figure, leading to the identification of segments whose lengths correspond to trigonometric functions and thus, facilitating the derivation of the addition formulas.

Angle Addition Identities

Angle addition identities for sine and cosine, such as sin(? + ?) = sin ? cos ? + cos ? sin ?, are fundamental trigonometric relationships. They allow the expression of the sine or cosine of a sum of two angles in terms of the sines and cosines of the individual angles. These identities are essential not only in algebraic manipulation but also in geometric proofs and applications involving rotations and oscillations.

Geometric Interpretation of Sine and Cosine

Sine and cosine can be interpreted as ratios of specific sides in a right triangle, with sine representing the ratio of the opposite side to the hypotenuse and cosine representing the ratio of the adjacent side to the hypotenuse. This geometric perspective is crucial in proofs and derivations because it connects angular measures with lengths and distances within constructed figures.
