Part 1: a Is it possible to add heat to a pure substance and...

Part 1: a Is it possible to add heat to a pure substance and not observe a temperature change? If so, provide examples. Describe, on a molecular level, what happens to the heat being added to a substance just before and during melting. Do any of these molecular changes cause a change in temperature? Part 2: Consider two pure substances with equal molar masses: substance A, having very strong intermolecular attractions, and substance $\mathrm{B}$, having relatively weak intermolecular attractions. Draw two separate heating curves for 0.25 -mol samples of substance $\mathrm{A}$ and substance $\mathrm{B}$ in going from the solid to the vapor state. You decide on the freezing point and boiling point for each substance, keeping in mind the information provided in this problem. Here is some additional information for constructing the curves. In both cases, the rate at which you add heat is the same. Prior to heating, both substances are at $-50^{\circ} \mathrm{C},$ which is below their freezing points. The heat capacities of $\mathrm{A}$ and $\mathrm{B}$ are very similar in all states. As you were heating substances $\mathrm{A}$ and $\mathrm{B}$, did they melt after equal quantities of heat were added to each substance? Explain how your heating curves support your answer. What were the boiling points you assigned to the substances? Are the boiling points the same? If not, explain how you decided to display them on your curves. c According to your heating curves, which substance reached the boiling point first? Justify your answer. Is the quantity of heat added to melt substance $\mathrm{A}$ at its melting point the same as the quantity of heat required to convert all of substance $\mathrm{A}$ to a gas at its boiling point? Should these quantities be equal? Explain.

Part 1:
a Is it possible to add heat to a pure substance and not observe a temperature change? If so, provide examples. Describe, on a molecular level, what happens to the heat being added to a substance just before and during melting. Do any of these molecular changes cause a change in temperature?

Part 2: Consider two pure substances with equal molar masses: substance A, having very strong intermolecular attractions, and substance $\mathrm{B}$, having relatively weak intermolecular attractions. Draw two separate heating curves for 0.25 -mol samples of substance $\mathrm{A}$ and substance $\mathrm{B}$ in going from the solid to the vapor state. You decide on the freezing point and boiling point for each substance, keeping in mind the information provided in this problem. Here is some additional information for constructing the curves. In both cases, the rate at which you add heat is the same. Prior to heating, both substances are at $-50^{\circ} \mathrm{C},$ which is below their freezing points. The heat capacities of $\mathrm{A}$ and $\mathrm{B}$ are very similar in all states.

As you were heating substances $\mathrm{A}$ and $\mathrm{B}$, did they melt after equal quantities of heat were added to each substance? Explain how your heating curves support your answer. What were the boiling points you assigned to the substances? Are the boiling points the same? If not, explain how you decided to display them on your curves.
c According to your heating curves, which substance reached the boiling point first? Justify your answer. Is the quantity of heat added to melt substance $\mathrm{A}$ at its melting point the same as the quantity of heat required to convert all of substance $\mathrm{A}$ to a gas at its boiling point? Should these quantities be equal? Explain.

Key Concepts

Intermolecular Forces

Intermolecular forces are the attractive forces between molecules that influence a substance's physical properties, such as melting and boiling points. Substances with strong intermolecular forces require more energy to break these bonds, resulting in higher melting and boiling points, whereas those with weaker forces require less energy. This concept is fundamental in understanding differences in heating curves and the amounts of heat needed for phase changes between different substances.

Heating Curves

Heating curves graphically represent how the temperature of a substance changes as heat is added. They typically display flat regions or plateaus during phase transitions where the temperature remains constant despite the continuous input of heat. These plateaus correspond to the points at which the substance is undergoing a phase change, reflecting the energy diverted into altering its internal structure rather than increasing kinetic energy.

Latent Heat

Latent heat is the energy required by a substance to undergo a phase change without a change in temperature. During transitions such as melting or boiling, the added heat energy is used to overcome intermolecular forces rather than increasing the kinetic energy of the particles, which is why the temperature remains constant during these processes.

Phase Transitions

Phase transitions refer to the processes in which a substance changes from one state of matter to another, such as solid to liquid (melting) or liquid to gas (vaporization). At the molecular level, during a phase change, the energy provided is used to break existing bonds or alter structural arrangements, leading to changes in physical state without a corresponding rise in temperature.

Transcript

00:02 Okay, so this is a large question.

00:05 Let's look at the question.

00:06 Part a.

00:09 The first question is that possible to add heat to a pure substance and not observe a temperature change.

00:17 If so, provide examples.

00:21 The answer is yes.

00:23 There's definitely such cases.

00:25 And the example is definitely very simple.

00:29 It is when you melt the sample, right? the ice melt from the water.

00:39 Actually, you say you are providing heat to the ice.

00:44 However, in this case, the temperature does not change.

00:51 And actually, this happens for all kinds of phase transitions, no matter from liquid to solid, from solid to gas.

01:01 During the phase transition, you are providing heat, however, the temperature does not change.

01:16 And now let's look at the second question.

01:19 Describe on a molecular level what happens to the heating being added to the substance just before and during the melting.

01:28 So from the molecular level, when you heat the sample and the melt, actually you are breaking down or break up.

01:43 Interactions between the molecules.

01:52 So what we say is actually the interaction between the molecules in the liquids actually is weaker than the solids.

02:07 So basically when you heat you're providing energy to break down those interactions.

02:15 So now we can look at the part two.

02:22 It says consider two pure substance with equal molar mass.

02:27 Substance a have very strong into molecular attractions than b, and it asks us to draw two heating curves for both samples, going from the solid state to vapor state, and you decide on the freezing point and the boiling point for each substance, keeping in mind the information provided in this problem.

02:54 Here is some additional information for your constructing the curves in both cases.

03:00 The heat rate is the same and the initial temperature is the same and heat capacity a and b are very similar.

03:10 So, okay, we can draw the diagram.

03:15 So i think the easiest way to draw is a temperature and time diagram.

03:26 So it says you are heating, you are increased the temperature and with a heating rate.

03:33 So it's easier to just draw a time than the temperature.

03:42 So initially it's at 50k.

03:51 So we first draw the a or b.

03:57 One thing that says a has stronger molecular interactions, which means a definitely has larger melting points.

04:10 And boiling point.

04:14 So if we draw a, we can kind of say, so first at 50k, and we increase the temperature.

04:25 And at certain points, we know that it will melt from solid.

04:34 And during the melt, as we mentioned earlier, the temperature will not change.

04:43 So when you heat, right, when time goes by, you're providing the energy, but the temperature does not change.

04:52 At a certain point, you will find that actually a other solid becomes liquid.

05:07 And in this case, you will keep continue, increase the temperature, because now the energy can be used to change the temperature.

05:20 And then once you reach a certain point, which we say it's a t1, t2.

05:33 At this point, the liquid starts to gasify.

05:39 So all the energy you provide will be used to break down or break up the interactions.

05:47 So the temperature will not change...
