Pinwheel The pinwheel in Fig. 5.1 .11 is obtained from the r-shape (Fig. 5.1.6) by a shear trans

Pinwheel The pinwheel in Fig. 5.1 .11 is obtained from the...

Key Concepts

Shear Transformation

A shear transformation is a linear mapping that displaces each point in a fixed direction, by an amount proportional to its signed distance from a line that is parallel to that direction. In a 2D setting, its matrix representation typically takes the form of a 2x2 matrix where one off?diagonal entry is nonzero and governs the shear factor. This transformation shifts points along one axis without altering areas, and its matrix is crucial for understanding how shapes can be distorted in a controlled linear manner.

Rotation Matrix

A rotation matrix in the plane is used to rotate points about the origin, and it is defined using sine and cosine functions of the rotation angle. For an angle ?, the rotation matrix is given by [[cos?, -sin?], [sin?, cos?]]. This form ensures that distances and angles are preserved during the transformation, making it a key tool in various geometric and algebraic contexts, including the analysis of successive rotations.

Composition of Transformations

When multiple linear transformations such as shears and rotations are applied successively, the overall effect can be determined by the multiplication of their corresponding matrices. This composition allows one to analyze how an initial shape is successively altered through different types of distortion and rotation. The order of these transformations is critical because matrix multiplication is not generally commutative.

Cyclic Groups and Rotation Orders

The concept of cyclic groups in the context of rotations involves repetitively applying a rotation until the original configuration is restored. Specifically, if a rotation matrix is applied repeatedly and the product equals the identity matrix after n rotations, then the set of rotations forms a cyclic group of order n. This idea is central to the study of symmetry and periodic patterns, as it examines the conditions under which a rotation returns a shape to its original orientation.

Transcript

00:01 In this video, we're told that t of theta, described as this matrix, will be the standard matrix for any transformation that rotates all vectors by an angle of theta in r2.

00:13 We're next told that we're going to verify this factorization formula that we see here.

00:19 We can verify this by multiplying each of the matrices in turn.

00:23 So let's start with these two multiply together.

00:26 We'll have that t of theta equals first, take cosine theta times 1 plus 0 times sine theta so we'll have a cosine theta in this entry next we take 0 times 1 plus 1 times sine theta so we'll have a sine theta here so that's our first column in this multiplication now to do the second column we'll be multiplying this vector with the corresponding entries in this row so cosine theta times 0 plus 0 times 1 gives us a 0 here then when we go to this row, we take 0 times 0 plus 1 times 1, and that gives us a 1.

01:10 So that's our first multiplication.

01:13 And just to make this easier for me to read, let me copy the next two matrices down.

01:19 We could multiply these in turn, but i think it's more efficient to work piece by piece.

01:27 So next matrix, 1 -0, negative tangent, theta, 1.

01:32 Now for the next step, i'm just going to focus on multiplying these two together.

01:38 So as before, in our multiplication, i'm going to focus on column one, start with row one here.

01:45 Take cosine theta times 1 plus 0 times 0, and we will have a cosine theta.

01:53 So let me write cosine theta here.

01:56 Next, we're going to be multiplying column 1 by the corresponding entries in row 2, so we have sine theta times 1 plus 1 times 0.

02:04 So a sine theta will go here.

02:08 Now we focus on column 2, multiply by corresponding entries in row 1, and we'll have cosine theta times 0 plus 0 times secant theta.

02:19 So just a 0 here.

02:21 And when we go to row 2, multiplying corresponding entries in column 2, we obtain just a secant of theta altogether.

02:30 Next, copy down the next matrix 1, negative tangent theta, 0 111, and proceed to multiply these last two matrices.

02:43 Recall our goal is to get to here.

02:46 If we can make it to this matrix, then we've verified the formula.

02:51 So now i'm going to focus on column 1, multiply by corresponding entries in row 1.

02:57 We'll have cosine theta times 1 plus 0 times 0.

03:00 So still there's a cosine theta here.

03:02 Now we're still in column 1, multiply by corresponding entries in row 2.

03:09 We'll have sine theta plus 0.

03:13 So sine theta will go here.

03:17 Now, so far we're in good shape because we have this entire column.

03:21 Next, i'm hoping for a negative sine theta in the next entry...
