Plot the ellipses Ek={T^k 𝐱 |𝐱=1} for k=1,2,3,4 for the following matrices T. Then determine the

step 1 So here we have two equations of ellipses, and we are asked to graph both of the ellipses on the

Plot the ellipses Ek={T^k 𝐱 |𝐱=1} for k=1,2,3,4 for the...

Plot the ellipses $E_k=\left\{T^k \mathbf{x} \mid\|\mathbf{x}\|=1\right\}$ for $k=1,2,3,4$ for the following matrices $T$. Then determine their principal axes, semi-axes, and areas. Hint: Use Exercise 8.7.23. (a) $\left(\begin{array}{rr}\frac{2}{3} & -\frac{1}{3} \\ -\frac{1}{3} & \frac{2}{3}\end{array}\right)$, (b) $\left(\begin{array}{cc}0 & -1.2 \\ .4 & 0\end{array}\right)$, (c) $\left(\begin{array}{ll}\frac{3}{5} & \frac{1}{5} \\ 2 & 4 \\ 5 & 5\end{array}\right)$.

Plot the ellipses $E_k=\left\{T^k \mathbf{x} \mid\|\mathbf{x}\|=1\right\}$ for $k=1,2,3,4$ for the following matrices $T$. Then determine their principal axes, semi-axes, and areas. Hint: Use Exercise 8.7.23.
(a) $\left(\begin{array}{rr}\frac{2}{3} & -\frac{1}{3} \\ -\frac{1}{3} & \frac{2}{3}\end{array}\right)$,
(b) $\left(\begin{array}{cc}0 & -1.2 \\ .4 & 0\end{array}\right)$,
(c) $\left(\begin{array}{ll}\frac{3}{5} & \frac{1}{5} \\ 2 & 4 \\ 5 & 5\end{array}\right)$.

Key Concepts

Linear Transformations and Their Powers

A linear transformation, represented by a matrix T, maps geometric objects like the unit circle into new shapes in the plane. When T is raised to a power k (yielding T^k), the transformation is applied repeatedly, resulting in a sequence of deformations. Each such transformation modifies the shape of the unit circle, often producing an ellipse. This concept is central to understanding how matrices function as operators on vector spaces, and their iterative applications reveal long?term geometric behavior.

Elliptical Image of the Unit Circle

When a linear transformation is applied to the unit circle, the result is typically an ellipse. The ellipse’s geometry—its orientation, the lengths of its semi-axes, and its area—is determined by the properties of the transformation matrix. The unit circle acts as the domain, and its image under T or T^k forms an ellipse whose characteristics provide insight into the stretching and contracting effect of the matrix on the plane.

Singular Value Decomposition (SVD)

Singular Value Decomposition is a factorization of a matrix into orthogonal matrices and a diagonal matrix of singular values. In the context of transforming a unit circle, the singular values indicate the lengths of the semi-axes of the resulting ellipse, while the corresponding orthogonal matrices determine the orientation (principal axes) of the ellipse. SVD is a powerful tool in linear algebra for analyzing the geometric action of any matrix, whether symmetric or not.

Eigenvalues, Eigenvectors, and the Spectral Theorem

In cases where the transformation matrix is symmetric, the spectral theorem guarantees that the matrix can be diagonalized with an orthonormal basis of eigenvectors. The eigenvalues indicate the amount of scaling in the direction of the corresponding eigenvectors. For such matrices, the ellipse’s principal axes are aligned with these eigenvectors, simplifying the determination of the semi-axes, which are related to the absolute values of the eigenvalues.

Area Transformation and Scaling

The area of the ellipse resulting from the transformation of the unit circle is directly related to the product of the lengths of its semi-axes. Specifically, the area can be computed using the formula A = ?ab, where a and b are the semi-axis lengths. This area scaling is an important property in linear transformations, where the determinant of the matrix indicates the factor by which areas (or volumes, in higher dimensions) are scaled.
