Professor John L. Krohn at Arkansas Tech University is running an engine test. At the beginning of the compression process in a hot air standard cycle, Otto cycle, the conditions are $p_1=14.7 \mathrm{psi}$, $T_1=77.0^{\circ} \mathrm{F}$. The compression ratio is 8.50 and the pressure doubles during the constant volume heat addition. For this cycle, use the air tables (Table C.16a) to determine the a. Heat addition per unit mass. b. Net work per unit mass. c. Hot ASC thermal efficiency. d. The maximum temperature reached in the cycle.

Professor John L. Krohn at Arkansas Tech University is running an engine test. At the beginning of the compression process in a hot air standard cycle, Otto cycle, the conditions are $p_1=14.7 \mathrm{psi}$, $T_1=77.0^{\circ} \mathrm{F}$. The compression ratio is 8.50 and the pressure doubles during the constant volume heat addition. For this cycle, use the air tables (Table C.16a) to determine the a. Heat addition per unit mass.
b. Net work per unit mass.
c. Hot ASC thermal efficiency.
d. The maximum temperature reached in the cycle.

Key Concepts

Use of Air Tables

Air tables provide tabulated thermodynamic properties of air, such as enthalpy, entropy, and specific heats, across a range of temperatures and pressures. They are used in the analysis of cycles like the Otto cycle, enabling accurate determination of state properties during the various processes when ideal gas assumptions are applied.

Otto Cycle

The Otto cycle is a thermodynamic cycle that models the functioning of a typical gasoline engine. It consists of two adiabatic (isentropic) processes and two constant volume processes, representing compression, heat addition at constant volume, expansion, and heat rejection at constant volume. This cycle forms the basis for analyzing engine performance, including efficiency and work output.

Air Standard Assumptions

Air standard assumptions simplify the analysis of internal combustion engines by treating the working fluid as an ideal gas that remains unchanged through the cycle. Real fuel combustion is replaced with heat addition and rejection processes, and air properties are used, often referencing air tables, to calculate thermodynamic properties and cycle performance.

Compression Ratio

The compression ratio is the ratio of the maximum to minimum volume in the cycle and is a key parameter affecting the efficiency of the engine. In the Otto cycle, a higher compression ratio typically leads to higher thermal efficiency, as it allows for a greater temperature increase during adiabatic compression, though practical limits exist to avoid engine knocking.

Constant Volume Heat Addition

In the Otto cycle, the heat addition process occurs at constant volume, meaning that the volume remains unchanged during the combustion event. This process leads to a sudden rise in pressure and temperature of the working fluid, which is critical in determining the cycle’s efficiency and the maximum cycle temperature.

Thermal Efficiency

Thermal efficiency is a measure of how effectively an engine converts heat into work. For the Otto cycle, the efficiency depends primarily on the compression ratio and the specific heat ratio of the working gas, offering insight into the maximum possible efficiency under ideal conditions.

Net Work Output

Net work output in an engine cycle is the difference between the work produced during the expansion process and the work consumed during the compression process. Calculating the net work output per unit mass is essential for evaluating the overall performance and energy conversion efficiency of the cycle.
