Railroad ties must be designed to resist large shear...

Railroad ties must be designed to resist large shear loadings. If the tie is subjected to the 34 -kip rail loadings and an assumed uniformly distributed ground reaction, determine the intensity $w$ for equilibrium, and calculate the maximum shear stress in the tie at section $a-a,$ which is located just to the left of the rail.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Critical Section Analysis

This is the process of identifying specific sections in a structural element where maximum stresses or internal forces may occur due to applied loads. In the problem, analysis at section a-a, just to the left of the rail, is essential for assessing the maximum shear stress in the tie.

Equilibrium

This concept involves ensuring that the sum of all forces and moments acting on a structure is zero. In the context of the problem, equilibrium is used to relate the rail loadings and the uniformly distributed ground reaction, allowing the determination of the necessary load intensity to maintain a balanced state.

Uniformly Distributed Load (UDL)

A uniformly distributed load is a load applied evenly along the length of a structure, expressed as a force per unit length. In this case, the UDL represents the ground reaction along the railroad tie and is a key parameter in calculating the overall load that the tie carries.

Shear Force and Maximum Shear Stress

Shear force refers to the internal force in a structural element that acts parallel to its cross-sectional area. Maximum shear stress is the highest stress experienced at a critical section of the element, like section a-a in the problem, and determining this stress is crucial for ensuring that the material can withstand the applied loads.
