Rationalize the following data. An Energy versus Reaction...

Rationalize the following data. An Energy versus Reaction progress diagram will be useful. Be sure to explain why the low-temperature product is mainly naphthalene-1-sulfonic acid, and why the high-temperature product is mainly naphthalene-2-sulfonic acid. Note that naphthalene-2sulfonic acid is more stable than naphthalene-1-sulfonic acid. You do not have to explain the relative energies of the two naphthalene sulfonic acids, although you might guess, and the answer will tell you. <smiles>c1ccc2ccccc2c1</smiles> $$ \text { concd } \mathrm{H}_{2} \mathrm{SO}_{4} \mid 40^{\circ} \mathrm{C} \quad \text { concd } \mathrm{H}_{2} \mathrm{SO}_{4} \mid 160^{\circ} \mathrm{C} $$ <smiles>O=S(=O)(O)c1ccc2ccccc2c1</smiles> <smiles>O=S(=O)(O)c1ccc2ccccc2c1</smiles> (minor)

Rationalize the following data. An Energy versus Reaction progress diagram will be useful. Be sure to explain why the low-temperature product is mainly naphthalene-1-sulfonic acid, and why the high-temperature product is mainly naphthalene-2-sulfonic acid. Note that naphthalene-2sulfonic acid is more stable than naphthalene-1-sulfonic acid. You do not have to explain the relative energies of the two naphthalene sulfonic acids, although you might guess, and the answer will tell you.
<smiles>c1ccc2ccccc2c1</smiles>
$$
\text { concd } \mathrm{H}_{2} \mathrm{SO}_{4} \mid 40^{\circ} \mathrm{C} \quad \text { concd } \mathrm{H}_{2} \mathrm{SO}_{4} \mid 160^{\circ} \mathrm{C}
$$
<smiles>O=S(=O)(O)c1ccc2ccccc2c1</smiles>
<smiles>O=S(=O)(O)c1ccc2ccccc2c1</smiles>
(minor)

Key Concepts

Reaction Energy Profiles

An energy versus reaction progress diagram is fundamental for visualizing the energy changes during a chemical reaction. It shows the activation energies required for the formation of intermediates and products, and ultimately indicates the relative stabilities of the different products. This diagram is useful in illustrating why a kinetically favored product may form at lower temperatures and why the thermodynamically more stable product is favored at higher temperatures.

Electrophilic Aromatic Substitution Mechanism

This mechanism, which is common in aromatic chemistry, involves the formation of an arenium ion intermediate when an electrophile attacks an aromatic ring. The stability of the intermediate and its subsequent deprotonation govern both the rate and the regioselectivity of the reaction. Temperature can influence which isomer is predominately formed by shifting the balance between kinetic accessibility and thermodynamic stability.

Kinetic vs Thermodynamic Control

This concept explains that under different reaction conditions, the product that forms fastest (kinetic product) might not be the most stable one, while conditions that allow for reversible reactions (thermodynamic control) will favor the product of lowest final energy. In many aromatic sulfonation reactions, low-temperature conditions lead to a product that forms more rapidly but is less stable, whereas high temperatures allow the reaction mixture to equilibrate, favoring the more stable product.
