Refer to Figure $10-2$ for problems 31 through 35 . FIGURE CANT COPY Figure 10-2 Summary review circuit. If a voltmeter connected across $R_1$ has a reading of 20 volts, it means that (a) $R_1$ is open (b) $R_3$ is shorted (c) $R_1$ is shorted (d) $R_2$ is open (e) $R_2$ and $R_4$ must be open._________

Refer to Figure $10-2$ for problems 31 through 35 .
FIGURE CANT COPY
Figure 10-2 Summary review circuit.
If a voltmeter connected across $R_1$ has a reading of 20 volts, it means that (a) $R_1$ is open (b) $R_3$ is shorted (c) $R_1$ is shorted (d) $R_2$ is open (e) $R_2$ and $R_4$ must be open._________

Key Concepts

Short Circuit Fault

A short circuit happens when a component or connection offers negligible resistance, creating an unintended low-resistance path. This can significantly alter the expected voltage distribution in the circuit by diverting current away from the normal paths, often causing near zero voltage drops across the shorted component and abnormal voltage readings elsewhere.

Fault Diagnosis in Circuit Analysis

Fault diagnosis in electrical circuits involves comparing measured quantities, such as voltages across components, with expected values calculated from circuit theory. By analyzing discrepancies—like a resistor showing a voltage drop equal to the supply voltage—engineers can infer which component, such as a resistor being open or a branch being shorted, has likely failed. This systematic approach is crucial for troubleshooting and repairing malfunctioning systems.

Voltage Division in Series Circuits

In a series circuit, the supply voltage is divided among the various resistors according to their resistances. This principle allows one to predict the voltage drop across each resistor under normal operating conditions. Deviations from the expected voltage drops can indicate that one of the circuit elements is not behaving as intended, such as when a resistor’s drop equals the full supply voltage instead of a fraction of it.

Open Circuit Fault

An open circuit occurs when a component or connection ceases to conduct current, creating a break in the circuit. This interruption prevents current flow past the point of the fault, which can lead to unexpected voltage measurements across components upstream from the open. For instance, if a resistor following R1 becomes open, R1 may exhibit a voltage drop equal to the entire supply voltage because no current flows beyond it.
