Refer to Figure 10.17 and the discussion of lights dimming when a heavy appliance comes on. (a) Given the voltage source is $120 \mathrm{V},$ the wire resistance is $0.800 \Omega$, and the bulb is nominally $75.0 \mathrm{W}$, what power will the bulb dissipate if a total of 15.0 A passes through the wires when the motor comes on? Assume negligible change in bulb resistance. (b) What power is consumed by the motor?

Key Concepts

Ohm's Law

Ohm's Law is a fundamental principle in electrical circuits that defines the relationship between voltage, current, and resistance. It states that the voltage across a resistor is equal to the product of the current flowing through it and its resistance. This relationship is essential for analyzing how currents and potential differences distribute throughout a circuit.

Voltage Drop

The concept of voltage drop refers to the reduction in voltage as electrical current passes through a resistance, such as wiring. In circuits where conductors have non-negligible resistance, the voltage available to components downstream is diminished. Understanding voltage drop is crucial in diagnosing issues like dimming lights when heavy loads cause additional current to flow.

Electrical Power

Electrical power in resistive elements is given by formulas such as P = V²/R or P = I²R, tying together the voltage across, current through, and resistance of the element. Accurate calculation of power consumption in a circuit is vital for ensuring components operate within safe limits and for understanding energy distribution when loads change.

Series Circuit Analysis

Series circuit analysis involves examining circuits where components are connected one after the other so that the same current flows through each. In these configurations, the total resistance is the sum of individual resistances, and the voltage supplied is divided among the elements. This analysis is critical for understanding how additional resistances, such as wiring, impact the performance of individual components in the circuit.
