Refer to Figure P3.2. Vane shear tests were conducted in the clay layer. The vane (tapered) dimensions were $63.5 \mathrm{~mm}(d) \times 127 \mathrm{~mm}(h), i_B=i_T=45^{\circ}$ (see Figure 3.23). For the test at $A$, the torque required to cause failure was $51 \mathrm{~N} \cdot \mathrm{m}$. For the clay, given: liquid limit $=46$ and plastic limit $=21$. Estimate the undrained cohesion of the clay for use in the design by using Bjerrum's $\lambda$ relationship $[$ Eq. (3.40a)].

Key Concepts

Vane Shear Test

The vane shear test is an in-situ testing method used primarily in geotechnical engineering to assess the undrained shear strength of cohesive soils like clays. It involves inserting a vane into the soil and applying a rotational force until failure occurs. The test is widely used because it does not require sample disturbance and can provide a direct measure of the soil's ability to resist shear deformation under undrained conditions.

Undrained Cohesion

Undrained cohesion represents the shear strength of a saturated clay under rapid loading conditions where drainage does not take place. It is a critical parameter in designing foundations and assessing soil stability. In an undrained state, the clay experiences strength from both its internal bonding and the pore water pressure, making the measurement of undrained cohesion fundamental for effective geotechnical analysis.

Plasticity Characteristics in Clays

The plasticity characteristics of a clay, quantified by the liquid limit and plastic limit, indicate its consistency and workability. The difference between these limits, known as the plasticity index, provides insight into the clay’s sensitivity to moisture changes and its overall mechanical behavior. These characteristics help engineers predict how a clay will behave under loading and are often correlated with its shear strength.

Bjerrum's Lambda Relationship

Bjerrum's Lambda Relationship is an empirical formula used to relate the plasticity characteristics of soil to its shear strength, particularly the undrained cohesion in clays. It utilizes parameters such as the liquid limit and plastic limit to estimate cohesion, thereby providing a means of designing and analyzing soil behavior when direct measurements of strength may be challenging or when adjustments based on soil plasticity are needed.

Conversion of Measured Torque to Cohesion

Converting the measured torque from a vane shear test into undrained cohesion involves accounting for the geometry and orientation of the vane as well as the stress distribution within the soil. This process typically employs theoretical relationships that consider the dimensions of the test apparatus and the assumed failure mechanisms, thus allowing the transformation of raw torque values into a practical estimate of soil shear strength.
