Refer to the following: Muscle $A$ and muscle $B$ are attached to a bone as indicated in the figure below. Muscle $A$ exerts a force on the bone at angle $\alpha,$ while muscle $B$ exerts a force on the bone at angle $\beta$. Assume muscle $A$ exerts a force of $1000 \mathrm{~N}$ on the bone at angle $\alpha=9^{\circ},$ while muscle $B$ exerts a force of $820 \mathrm{~N}$ on the bone at angle $\beta=38^{\circ} .$ Find the resultant force and the angle of the force due to muscle $A$ and muscle $B$ on the bone.

Refer to the following:
Muscle $A$ and muscle $B$ are attached to a bone as indicated in the figure below. Muscle $A$ exerts a force on the bone at angle $\alpha,$ while muscle $B$ exerts a force on the bone at angle $\beta$.
Assume muscle $A$ exerts a force of $1000 \mathrm{~N}$ on the bone at angle $\alpha=9^{\circ},$ while muscle $B$ exerts a force of $820 \mathrm{~N}$ on the bone at angle $\beta=38^{\circ} .$ Find the resultant force and the angle of the force due to muscle $A$ and muscle $B$ on the bone.

Key Concepts

Angle Calculation

Angle calculation involves determining the direction of the resultant vector with respect to a reference direction, usually by taking the inverse tangent (arctan) of the ratio of the vertical component to the horizontal component. This gives the orientation of the resultant force in space.

Resultant Force

The resultant force is the single force that has the same effect as the combined forces acting on an object. It is computed by summing the individual vector components and then using the Pythagorean theorem to find its magnitude.

Vector Addition

Vector addition is the process of combining two or more vectors to produce a resultant vector. In physics, especially in mechanics, forces are vectors, and their combined effect is determined by adding their respective components, allowing for the examination of net force or displacement.

Component Resolution

Component resolution involves breaking down vectors into perpendicular components, typically along the horizontal (x-axis) and vertical (y-axis) directions. This simplifies the addition of vectors as each component can be summed independently, which is essential when dealing with vectors at various angles.

Trigonometric Functions

Trigonometric functions such as sine and cosine are used to calculate the components of a vector when the vector’s magnitude and the angle it makes with a reference axis are known. Cosine gives the horizontal component while sine gives the vertical component.
