00:02
So this is a question involving thin film interference, and here is the basic idea of what's going on.
00:11
We have three different media involved.
00:15
The light ray is passing through.
00:19
Typically when these calculations are made, the light ray impinges on the interface between the two media perpendicularly, so you don't have to worry about phenomenon like refraction.
00:34
But to make it easier to see, i'm going to have the light rays coming in at an angle to the normal.
00:41
So let's say we have a light ray coming in like this, and it's in medium one, and when it passes from medium one to medium two, maybe it refracts.
00:53
I'm going to say refracts toward the normal here, but it also reflects.
01:04
So part of the light ray gets refracted, and part of the light ray reflects back up.
01:10
Of course the angle of incidence equals the angle of reflection, just like it always does.
01:15
And when the light ray encounters the second interface between these three media, it can also reflect.
01:26
And so it's going to go over here, and then when it reflects out, it's going to revert back to the path of the other reflected light ray, and be like this.
01:38
So we have these two reflected light rays now, one reflected off the top interface, and the other reflected off the bottom interface.
01:46
And the question is, will these light rays interfere constructively or destructively? well, the basic idea is this.
01:58
If one of the light rays had to go an extra full wavelength, then the light rays will interfere constructively.
02:11
Now there's exceptions to that, i'll talk about that in just a moment, but the basic idea is we want the light ray that got refracted first, and so it went into the second medium, and then it reflected off that second interface, went back up.
02:24
We want the second light ray to have gone an entire wavelength farther in order for it to interfere constructively with the other light ray.
02:38
And by the way, keep in mind that these light rays are supposed to be going perpendicular to the interfaces, and so one whole wavelength farther would mean that this distance here, d, would be equal to one half of a wavelength.
02:58
Because that would be, don't worry about any angles here, the light rays are just kind of going straight down and straight back up, and so the path length difference for light ray number two compared to light ray number one, if they're going straight into the medium and straight back out, is going to be lambda when the distance between the two layers is one half of a wavelength.
03:22
Now there is an exception though, there is a complicating factor.
03:25
Let us talk about the indices of refraction of these materials.
03:29
Let's say this is n1, an extra fraction n1, an extra fraction n2, an extra fraction of n3.
03:36
Because there is something that happens to light when it does reflect.
03:41
Just like when we have like a wave traveling on a rope or a thin spring traveling down and encounters a barrier, and so part of that wave gets bounced back.
03:54
And we find that under certain conditions where the end of the string is fixed, that when the wave bounces back, it actually gets inverted.
04:03
So if we have a peak going up, going into the fixed point, then we're going to have a peak going down, reflecting off of that fixed point.
04:12
On the other hand, if that point is free to move, then it doesn't get inverted.
04:17
It just, if we have a peak pointing up going in, we get a peak pointing up going out.
04:23
A similar thing happens here.
04:25
It turns out that if a wave reflects off of a surface where the index of refraction of the material underneath it is higher than the incident medium's index of refraction, the wave is going to be inverted.
04:41
So this is like reflection off of a fixed boundary.
04:45
On the other hand, if a wave goes in and it reflects off of a surface, the material of which is of a lower index of refraction, the wave does not get inverted.
05:00
So let's take a look at each case here and see what is happening with our waves.
05:07
Let's write those two rules down, though, just so we have them handy.
05:12
So if into higher index, i'm going to say it like that, into a higher index, from a lower index into a higher index, the reflected wave doesn't go into the new material.
05:29
But if it's reflecting off of something that has a higher index, into a higher index, wave is inverted.
05:41
I'm just going to say flipped.
05:46
Whereas if the wave is going into a lower index material, then that is a wave is not flipped.
06:08
Wave is upright.
06:11
So we'll keep those two rules in mind and we'll see what happens here.
06:17
So let's take a look at case one.
06:21
We have a light ray coming in and it's going through a material with an index of refraction of 1 .6 and it's encountering a material with an index of refraction of 1 .5.
06:33
And then the transmitted portion of that wave is going to encounter a material that is of an index of refraction of 1 .4.
06:40
So in both cases, neither wave gets flipped because they're always going from a higher index to a lower index...
