Saturated moist air at $15^{\circ} \mathrm{C}$ and standard atmospheric pressure undergoes a process which has a sensible-heat ratio of $\mathrm{SHR}=0.70$. After the process, the dry-bulb temperature is $40^{\circ} \mathrm{C}$. By the psychrometric chart, determine the following at the end of the process: (a) humidity ratio, (b) dew-point temperature, (c) relative humidity, and (d) wet-bulb temperature.

Saturated moist air at $15^{\circ} \mathrm{C}$ and standard atmospheric pressure undergoes a process which has a sensible-heat ratio of $\mathrm{SHR}=0.70$. After the process, the dry-bulb temperature is $40^{\circ} \mathrm{C}$. By the psychrometric chart, determine the following at the end of the process:
(a) humidity ratio,
(b) dew-point temperature,
(c) relative humidity, and
(d) wet-bulb temperature.

Key Concepts

Sensible Heat Ratio

The sensible heat ratio (SHR) is the fraction of the total heat added or removed in a process that results in a temperature change (sensible heat) as opposed to changing the moisture content (latent heat). It is important for characterizing and designing processes involving humid air, particularly when both temperature and humidity are being modified.

Wet-Bulb Temperature

The wet-bulb temperature is the lowest temperature that can be reached by evaporative cooling of air. It is measured by a thermometer with a wetted bulb and is used to assess the potential for evaporation and cooling in meteorological and HVAC applications.

Relative Humidity

Relative humidity is the ratio, expressed as a percentage, of the actual water vapor content in the air to the maximum possible water vapor content at the same temperature. It provides a measure of how close the air is to being saturated and plays a significant role in comfort, weather, and various engineering applications.

Psychrometric Chart

A psychrometric chart is a graphical representation that illustrates the thermodynamic properties of moist air, including dry-bulb temperature, wet-bulb temperature, humidity ratio, and relative humidity. It is an essential tool for analyzing processes involving air-water vapor mixtures, allowing engineers to determine the state of the air before and after various heating, cooling, moistening, or dehumidifying processes.

Humidity Ratio

The humidity ratio, also known as the moisture content, is the ratio of the mass of water vapor to the mass of dry air in a moist air sample. It is a fundamental property used in psychrometrics to quantify the amount of moisture present in the air independently of air temperature and pressure.

Dew-Point Temperature

The dew-point temperature is the temperature at which air becomes saturated with water vapor, causing condensation to begin. It is a critical parameter for determining moisture-related phenomena, such as fog, dew formation, or the onset of condensation in cooling processes.
