Select the correct answer for the statements in items 10 through 14, and place the corresponding letter in the space provided. __________________________________ A synchronous motor with an underexcited DC field has _____________________ a. a leading power factor. b. a lagging power factor. c. less synchronous speed. d. no effect.

Select the correct answer for the statements in items 10 through 14, and place the corresponding letter in the space provided. __________________________________
A synchronous motor with an underexcited DC field has _____________________
a. a leading power factor.
b. a lagging power factor.
c. less synchronous speed.
d. no effect.

Key Concepts

Power Factor (Lagging and Leading)

Power factor is a measure of how effectively electrical power is converted into mechanical work. It is influenced by the phase relationship between voltage and current. In the context of synchronous machines, a lagging power factor indicates that the motor is absorbing reactive power (as seen in underexcited conditions), while a leading power factor usually occurs when the machine supplies reactive power back to the system (as seen in overexcited conditions).

Underexcitation

Underexcitation occurs when the field current supplied to a synchronous motor is lower than what is needed for optimal operation. This results in a weaker magnetic field, causing the motor to draw reactive power from the supply, which typically leads to a lagging power factor.

Field Excitation

Field excitation refers to the process of supplying DC current to the rotor windings in a synchronous machine. This controlled excitation is crucial for establishing and regulating the magnetic field, which in turn affects the motor’s voltage, stability, and reactive power behavior.

Synchronous Motors

Synchronous motors are AC machines that run at a constant speed determined by the frequency of the supply and the number of poles in the motor. They rely on a DC excited rotor to create a magnetic field that interacts with the stator’s rotating field, thus converting electrical energy into mechanical power.

Select the correct answer for the statements in items 10 through 14, and place the corresponding letter in the space provided. ______________ A synchronous motor with an underexcited DC field has _ a. a leading power factor. b. a lagging power factor. c. less synchronous speed. d. no effect.
