Seven factors are varied at two levels in an experiment involving only 16 trials. A $\frac{1}{8}$ fraction of a $2^{7}$ factorial experiment is used, with the defining contrasts being $A C D, B E F,$ and $C E G .$ The data are as follows: $$ \begin{array}{cc|lc} \text { Treat. } & & \text { Treat. } & \\ \text { Comb. } & \text { Response } & \text { Comb. } & \text { Response } \\ \hline(1) & 31.6 & a c g & 31.1 \\ a d & 28.7 & c d g & 32.0 \\ a b c e & 33.1 & \text { beg } & 32.8 \\ \text { cdef } & 33.6 & \text { adefg } & 35.3 \\ \text { acef } & 33.7 & \text { efg } & 32.4 \\ \text { bcde } & 34.2 & \text { abdeg } & 35.3 \\ \text { abdf } & 32.5 & \text { bcdf } g & 35.6 \\ \text { bf } & 27.8 & \text { abcfg } & 35.1 \end{array} $$ Perform an analysis of variance on all seven main effects, assuming that interactions are negligible. Use a 0.05 level of significance.

Seven factors are varied at two levels in an experiment involving only 16 trials. A $\frac{1}{8}$ fraction of a $2^{7}$ factorial experiment is used, with the defining contrasts being $A C D, B E F,$ and $C E G .$ The data are as follows:
$$
\begin{array}{cc|lc}
\text { Treat. } & & \text { Treat. } & \\
\text { Comb. } & \text { Response } & \text { Comb. } & \text { Response } \\
\hline(1) & 31.6 & a c g & 31.1 \\
a d & 28.7 & c d g & 32.0 \\
a b c e & 33.1 & \text { beg } & 32.8 \\
\text { cdef } & 33.6 & \text { adefg } & 35.3 \\
\text { acef } & 33.7 & \text { efg } & 32.4 \\
\text { bcde } & 34.2 & \text { abdeg } & 35.3 \\
\text { abdf } & 32.5 & \text { bcdf } g & 35.6 \\
\text { bf } & 27.8 & \text { abcfg } & 35.1
\end{array}
$$
Perform an analysis of variance on all seven main effects, assuming that interactions are negligible. Use a 0.05 level of significance.

Key Concepts

Significance Level and Hypothesis Testing

A significance level (commonly set at 0.05) defines the threshold for rejecting the null hypothesis in hypothesis tests. In the context of factorial experiments, each factor’s effect is tested to determine if it is statistically significant, indicating that the observed effect is unlikely to be due to random chance.

Assumption of Negligible Interactions

Assuming that interactions between factors are negligible simplifies the analysis by focusing solely on the main effects. This assumption allows experimenters to attribute variations in the response primarily to individual factors, though it must be checked or justified since significant interactions can mislead conclusions.

Main Effects

The main effect of a factor represents the average change in the response when the factor is changed from one level to another, independent of the other factors. In the context of factorial experiments, estimating and testing the significance of main effects is essential to identify which factors influence the response.

Analysis of Variance (ANOVA) in Factorial Experiments

ANOVA is a statistical method used to partition the observed variation in response data into components attributable to different sources, such as main effects and error. In factorial experiments, ANOVA helps in testing whether the effects of various factors are statistically significant based on the variability and degrees of freedom allocated to each source.

Defining Relation and Alias Structure

In fractional factorial experiments, the defining relation specifies the confounding pattern among factors. It indicates which effects are aliased with each other, meaning that the estimate for one effect may actually represent a combination of effects. This information is crucial for correctly interpreting the results and understanding limitations in effect estimation.

Fractional Factorial Design

A fractional factorial design is an experimental setup where only a subset of the full factorial combinations is used. This approach is especially useful when the number of factors is large, allowing efficient estimation of main effects and some interactions while reducing the number of required experimental runs.
