Show that the impedance of a real transmission line seen from a position $x$ on the line is given by $$ Z_{x}=Z_{0} \frac{A \mathrm{e}^{-\gamma}-B \mathrm{e}^{+\gamma x}}{A \mathrm{e}^{-\gamma}+B \mathrm{e}^{+\gamma x}} $$ where $\gamma$ is the propagation constant and $A$ and $B$ are the current amplitudes at $x=0$ of the waves travelling in the positive and negative $x$ -directions respectively. If the line has a length $I$ and is terminated by a load $Z_{L}$, show that $$ Z_{L}=Z_{0} \frac{A \mathrm{e}^{-\gamma l}-B \mathrm{e}^{\gamma l}}{A \mathrm{e}^{-\gamma l}+B \mathrm{e}^{\gamma l}} $$

Show that the impedance of a real transmission line seen from a position $x$ on the line is given by
$$
Z_{x}=Z_{0} \frac{A \mathrm{e}^{-\gamma}-B \mathrm{e}^{+\gamma x}}{A \mathrm{e}^{-\gamma}+B \mathrm{e}^{+\gamma x}}
$$
where $\gamma$ is the propagation constant and $A$ and $B$ are the current amplitudes at $x=0$ of the waves travelling in the positive and negative $x$ -directions respectively. If the line has a length $I$ and is terminated by a load $Z_{L}$, show that
$$
Z_{L}=Z_{0} \frac{A \mathrm{e}^{-\gamma l}-B \mathrm{e}^{\gamma l}}{A \mathrm{e}^{-\gamma l}+B \mathrm{e}^{\gamma l}}
$$

Key Concepts

Load Termination

Load termination involves connecting a load impedance (such as ZL) to the end of a transmission line, and it significantly influences the reflected wave amplitude. In the analysis of transmission lines, proper termination is used to relate the amplitudes of the incident and reflected waves at the line end, thereby connecting the load impedance with the characteristic impedance of the line and the propagation behavior represented by the exponential terms.

Transmission Line Theory

Transmission line theory deals with the analysis of electrical transmission lines using distributed circuit models. It considers how voltage and current vary along the length of a transmission line due to its physical properties represented as distributed inductance, capacitance, resistance, and conductance. This approach is critical for understanding wave propagation, reflections, impedance matching, and energy transmission in high-frequency circuits.

Characteristic Impedance

The characteristic impedance, often denoted as Z?, is a fundamental property of a transmission line that represents the ratio of voltage to current for a single propagating wave along the line when the line is infinitely long or properly terminated. It is intrinsic to the line's geometry and material properties and is key in analyzing impedance mismatches and standing wave phenomena.

Propagation Constant

The propagation constant, denoted by ?, is a complex quantity that describes how a wave attenuates and experiences phase change as it propagates along a transmission line. Its real part indicates the rate of amplitude attenuation, while its imaginary part represents the phase shift per unit length. This constant is central in determining the exponential variation of the wave’s amplitude and phase along the line.

Traveling Waves

The concept of traveling waves entails decomposing the voltage and current on a transmission line into forward and backward propagating wave components. These components, with amplitudes A and B respectively, simplify the analysis by allowing the representation of the overall wave behavior as the superposition of waves traveling in opposite directions. This decomposition is essential in deriving expressions for impedance along the transmission line.
