Show that the system of momenta for a rigid body in plane motion reduces to a single vector, and express the distance from the mass center $G$ to the line of action of this vector in terms of the centroidal radius of gyration $\bar{k}$ of the body, the magnitude $\bar{v}$ of the velocity of $G,$ and the angular velocity $\omega .$

Key Concepts

Line of Action of a Moment

The line of action is the line along which a force or moment effectively acts. In the context of rigid body dynamics, it is often useful to identify the unique line along which the total moment (combining translational and rotational effects) is applied. Expressing the distance from the center of mass to this line in terms of the centroidal radius of gyration, translational velocity, and angular velocity provides key insights into the dynamic behavior of the body.

Centroidal Radius of Gyration

The centroidal radius of gyration is a parameter that characterizes the distribution of a body’s mass about its center of mass. It is defined such that the moment of inertia about the center of mass equals the mass multiplied by the square of this radius. This concept is crucial in linking the rotational inertia of the body to its geometric and mass properties, and it appears naturally in expressions relating rotational quantities to translational ones.

Rigid Body Dynamics

This concept deals with the motion of objects that do not deform, combining both translation (movement of the center of mass) and rotation (about an axis). In plane motion, these two aspects are coupled, which allows the system’s dynamics to be analyzed in a simplified, two-dimensional manner.

Angular Momentum (Moment of Momentum)

Angular momentum is a measure of the rotational effect of forces acting on a body about a point. For a rigid body in plane motion, its angular momentum includes a contribution from the translational motion of the center of mass and another from the rotation about the center of mass. Notably, because the rotation is in a plane, the angular momentum vector is perpendicular to that plane, effectively reducing the system of momenta to a single vector.
