Sketch the transfer characteristics of a p -channel enhancement-type MOSFET if VT=-5 V and k=0.

step 1 So for part A, for the condition that VGD equals to 0, and from VGS equal VDS plus VGD, we have

Sketch the transfer characteristics of a p -channel...

Key Concepts

p-channel MOSFET

A p-channel MOSFET is a type of metal–oxide–semiconductor field-effect transistor where the charge carriers are holes. In these devices, the source and drain are doped with p-type material. To operate these transistors, the gate-to-source voltage must be such that it attracts holes into the channel, allowing current flow from the source to the drain.

Enhancement-mode Operation

Enhancement-mode devices are normally off at zero bias; that is, there is no conductive channel without an appropriate gate voltage. For a p-channel enhancement-mode MOSFET, the device begins to conduct when the gate-to-source voltage becomes more negative than the threshold voltage, thereby creating an inversion layer for hole conduction.

Threshold Voltage

The threshold voltage is the critical voltage at which an inversion layer forms, allowing significant current to flow between the source and the drain. In the context of a p-channel MOSFET, the threshold voltage is negative; conduction starts when the gate-to-source voltage is below this negative value, ensuring that sufficient charge carriers accumulate in the channel.

Transconductance Parameter (k)

The transconductance parameter, often denoted by k, quantifies the efficiency with which the gate voltage modulates the channel current. In the quadratic model of MOSFET operation, the drain current in the saturation region is proportional to the parameter k and the square of the voltage difference beyond the threshold, making it a key factor in defining the transfer characteristics.

Transfer Characteristics

Transfer characteristics describe the relationship between the gate-to-source voltage and the resulting drain current. They typically feature a cutoff region (where the device is off), a linear region near the threshold, and a quadratic increase in the saturation region. Understanding these characteristics is crucial for predicting and designing the behavior of the MOSFET in circuits.
