Skewed Michelson-Morley apparatus In Section $12.3$ arm A of the Michelson-Morley interferometer was assumed to be along the line of motion and arm B perpendicular, and the predicted time difference according to the ether theory was $$ \Delta \tau=\frac{l}{c}\left(\frac{v^{2}}{c^{2}}\right) $$ Calculate the expected time difference if $\operatorname{arm} \mathrm{A}$ is at angle $\theta$ to the line of motion through the ether, as shown.

Skewed Michelson-Morley apparatus In Section $12.3$ arm A of the Michelson-Morley interferometer was assumed to be along the line of motion and arm B perpendicular, and the predicted time difference according to the ether theory was
$$
\Delta \tau=\frac{l}{c}\left(\frac{v^{2}}{c^{2}}\right)
$$
Calculate the expected time difference if $\operatorname{arm} \mathrm{A}$ is at angle $\theta$ to the line of motion through the ether, as shown.

Key Concepts

Geometry of Light Paths in Moving Frames

The analysis of light paths when an interferometer's arm is at an arbitrary angle to the direction of motion requires a geometric decomposition of velocities. By resolving components of the apparatus's velocity relative to the light’s path, one can compute how the angle affects the travel times, leading to modified predictions for time differences.

Time Difference Computation in Interferometry

In interferometric experiments, differences in travel time of light along different paths are calculated by considering the effective speed of light along each arm of the apparatus. This method involves determining how the motion of the apparatus alters the round trip times, resulting in observable interference fringes.

Ether Theory

Ether theory posited that a stationary medium, called the ether, permeated all space and served as the carrier for light waves. The theory predicted that the speed of light would vary depending on the motion of the apparatus through the ether, leading to measurable time differences in light paths.

Michelson-Morley Experiment

This experiment was designed to detect differences in the speed of light along different directions in an interferometer, based on the principle that Earth's motion through a supposed ether would affect light’s travel time. Its null results were pivotal in challenging the ether hypothesis and paving the way for the theory of relativity.
