Solve Prob. 3.55, assuming that the shaft A B is replaced by a hollow shaft of the same outer di

step 1 In this situation, we have to find the torsional strain energy in the shaft. So if we draw the f

Solve Prob. 3.55, assuming that the shaft A B is replaced by...

Key Concepts

Hollow Shaft Geometry

A hollow shaft has a cylindrical cross-section with a void in the center, which reduces weight while potentially maintaining sufficient strength under torsional loading. The design requires careful consideration of both the outer and inner diameters because these dimensions directly influence the polar moment of inertia and therefore the shaft’s resistance to twisting and stress. Hollow shafts are often chosen in mechanical applications where weight saving is crucial without compromising mechanical performance.

Torsional Analysis

This concept involves understanding how a torque applied to a shaft induces a twisting effect, generating shear stresses that vary across the cross-section. In mechanical design, formulas such as ? = T?/J and ? = TL/JG are used to compute the shear stress and angle of twist in circular shafts, where T is the applied torque, ? is the radial distance, J is the polar moment of inertia, L is the length of the shaft, and G is the shear modulus. It is fundamental for ensuring that the shaft can safely transmit the required torque without failure.

Polar Moment of Inertia

The polar moment of inertia is a geometric property that quantifies a cross-section's resistance to torsion. For hollow shafts, it is calculated by subtracting the inner circular section’s contribution from that of the outer circle, typically using the formula J = (?/32)·(d_outer^4 ? d_inner^4). Understanding and computing the polar moment is critical for determining the stresses and deformations in both solid and hollow circular shafts under torsional loads.
