Question

Speculate on why chlorine is stored as a liquid rather than being purchased and stored as a gas at the absorber temperature $\left(25^{\circ} \mathrm{C}\right),$ when storing it as a gas would eliminate the need for the chlorine vaporizer and possibly for the heat exchanger in the chlorine feed line. The chlorine fed to the tank dissolves in both the liquid phase and the polymer phase. The slurry inside the tank is well mixed, so that its composition is the same as the composition of the exiting stream. The head space above the slurry contains chlorine vapor in equilibrium with the dissolved chlorine in both condensed phases and water vapor in equilibrium with the liquid water in the aqueous phase. The condition inside the absorber is shown schematically in the following diagram: The following physical property data pertain to this system: $\cdot$ The solubilities of $\mathrm{Cl}_{2}$ in $\mathrm{PVC}$ and in water are correlated by a form of Henry's law: $$x_{\mathrm{p}}\left(\mathrm{kg} \mathrm{Cl}_{2} / \mathrm{kg} \mathrm{PVC} \text { phase }\right)=\alpha_{\mathrm{p}} p_{\mathrm{C}_{2}}, \quad x_{\mathrm{a}}\left(\mathrm{kg} \mathrm{Cl}_{2} / \mathrm{kg} \text { aqueous phase }\right)=\alpha_{\mathrm{a}} p_{\mathrm{Cl}_{2}}$$ where $p_{\mathrm{C}_{2}}$ is the partial pressure of chlorine in the head space. The coefficients $\alpha_{\mathrm{p}}$ and $\alpha_{\mathrm{a}}$ depend on the system temperature. $\cdot$ The solubility data shown below have been obtained for chlorine in $\mathrm{PVC}$ at $25^{\circ} \mathrm{C}$ : $$\begin{array}{|l|c|c|c|c|c|c|c|} \hline p_{\mathrm{Cl}_{2}}(\mathrm{atm}) & 0.75 & 1.18 & 1.23 & 2.95 & 3.03 & 3.87 & 4.82 \\ \hline \mathrm{wt} \% \mathrm{Cl}_{2} & 2.9 \% & 4.6 \% & 5.1 \% & 11.9 \% & 12.3 \% & 15.4 \% & 19.8 \% \\ \hline \end{array}$$ $\cdot$ At $25^{\circ} \mathrm{C},$ chlorine gas is 2.68 times more soluble in $\mathrm{PVC}$ than in water for any chlorine partial pressure. $\cdot$ Raoult's law provides a good correlation of the equilibrium between liquid water and water vapor in the system.

Name: Problem 7, Chapter 12: Elementary Principles of Chemical Processes
Uploaded: 2021-02-10T10:02:31-08:00
Duration: 3 min 38 s
Channel: Lottie Adams

   Speculate on why chlorine is stored as a liquid rather than being purchased and stored as a gas at the absorber temperature $\left(25^{\circ} \mathrm{C}\right),$ when storing it as a gas would eliminate the need for the chlorine vaporizer and possibly for the heat exchanger in the chlorine feed line.
The chlorine fed to the tank dissolves in both the liquid phase and the polymer phase. The slurry inside the tank is well mixed, so that its composition is the same as the composition of the exiting stream. The head space above the slurry contains chlorine vapor in equilibrium with the dissolved chlorine in both condensed phases and water vapor in equilibrium with the liquid water in the aqueous phase. The condition inside the absorber is shown schematically in the following diagram:
The following physical property data pertain to this system:
$\cdot$ The solubilities of $\mathrm{Cl}_{2}$ in $\mathrm{PVC}$ and in water are correlated by a form of Henry's law:
$$x_{\mathrm{p}}\left(\mathrm{kg} \mathrm{Cl}_{2} / \mathrm{kg} \mathrm{PVC} \text { phase }\right)=\alpha_{\mathrm{p}} p_{\mathrm{C}_{2}}, \quad x_{\mathrm{a}}\left(\mathrm{kg} \mathrm{Cl}_{2} / \mathrm{kg} \text { aqueous phase }\right)=\alpha_{\mathrm{a}} p_{\mathrm{Cl}_{2}}$$
where $p_{\mathrm{C}_{2}}$ is the partial pressure of chlorine in the head space. The coefficients $\alpha_{\mathrm{p}}$ and $\alpha_{\mathrm{a}}$ depend on the system temperature.
$\cdot$ The solubility data shown below have been obtained for chlorine in $\mathrm{PVC}$ at $25^{\circ} \mathrm{C}$ :
$$\begin{array}{|l|c|c|c|c|c|c|c|}
\hline p_{\mathrm{Cl}_{2}}(\mathrm{atm}) & 0.75 & 1.18 & 1.23 & 2.95 & 3.03 & 3.87 & 4.82 \\
\hline \mathrm{wt} \% \mathrm{Cl}_{2} & 2.9 \% & 4.6 \% & 5.1 \% & 11.9 \% & 12.3 \% & 15.4 \% & 19.8 \% \\
\hline
\end{array}$$
$\cdot$ At $25^{\circ} \mathrm{C},$ chlorine gas is 2.68 times more soluble in $\mathrm{PVC}$ than in water for any chlorine partial pressure.
$\cdot$ Raoult's law provides a good correlation of the equilibrium between liquid water and water vapor in the system.

Elementary Principles of Chemical Processes

Richard M. Felder,… 3rd Edition

Chapter 12, Problem 7

Instant Answer

Solved by Expert Lottie Adams

02/10/2021

Step 1

Safety: Storing chlorine as a liquid is safer than storing it as a gas. In case of a leak, liquid chlorine would evaporate slowly, while gaseous chlorine would spread rapidly, posing a higher risk to people and the environment. Show more…
