Table 9.1 shows the numerical results obtained from Blasius exact solution of the laminar boundary-layer equations. Plot the velocity distribution (note that from Eq. 9.13 we see that $\eta \approx 5.0 \frac{y}{\delta}$ ). On the same graph, plot the turbulent velocity distribution given by the $\frac{1}{7}$ -power expression of Eq. $9.24 .$ Which is most likely to separate first when encountering an adverse pressure gradient? To justify your answer, compare the momentum fluxes of these profiles (the laminar data can be integrated using a numerical method such as Simpson's rule $)$.

Key Concepts

Laminar Boundary Layer

The laminar boundary layer is a thin region adjacent to a solid surface where viscous effects dominate and the fluid flows in smooth, parallel layers without mixing. The Blasius solution specifically provides a similarity solution for the steady, two-dimensional laminar boundary layer on a flat plate, describing how the velocity transitions from zero at the surface to the free stream value farther away.

Turbulent Boundary Layer

In contrast to laminar flow, a turbulent boundary layer exhibits chaotic fluctuations and mixing, which enhance momentum transfer and delay the formation of strong velocity gradients. The 1/7-power law is an empirical expression that approximates the velocity distribution within a turbulent boundary layer, capturing the effect of increased momentum diffusion due to turbulence.

Velocity Profile

A velocity profile represents the variation of flow velocity across the boundary layer from the wall to the free stream. It is crucial for understanding how momentum is distributed within the boundary layer and forms the basis for further analysis of shear stress, drag, and stability under various flow conditions.

Adverse Pressure Gradient

An adverse pressure gradient occurs when the pressure increases in the direction of the flow, which can decelerate the fluid near the wall. This phenomenon is significant because it can lead to boundary layer separation, where the flow detaches from the surface, impacting performance in engineering applications by increasing drag and reducing lift.

Momentum Flux

Momentum flux in the context of boundary layers refers to the rate at which momentum is transferred across a given surface within the flow. The momentum flux, often calculated from the velocity profile, is used to assess the ability of the flow to withstand adverse pressure gradients. Profiles with lower momentum flux near the wall are more susceptible to separation.

Numerical Integration (Simpson's Rule)

Simpson's rule is a numerical integration technique used to approximate the integral of a function when an analytical solution is difficult to obtain. In boundary layer analysis, Simpson's rule can be employed to integrate the velocity profile in order to compute the momentum flux, thereby quantifying the stability of the flow and its propensity for separation under adverse pressure gradients.
