The 50,000 -lb flatear supports a 15,000 -lb vehicle on a 5^∘ ramp built on the flatear. If the

step 1 So here on this problem we are given that a flat car supports a vehicle that has a mass of 15 ,0

The 50,000 -lb flatear supports a 15,000 -lb vehicle on a...

The 50,000 -lb flatear supports a 15,000 -lb vehicle on a $5^{\circ}$ ramp built on the flatear. If the vehicle is released from rest with the flatear also at rest, determine the velocity $v$ of the flatcar when the vehicle has rolled $s=40 \mathrm{ft}$ down the ramp just before hitting the stop at $B$. Neglect all friction and treat the vehicle and the flatcar as particles.

Labs

Want to see this concept in action?

NEW

Explore this concept interactively to see how it behaves as you change inputs.

View Labs

Key Concepts

Relative Motion Analysis

This concept is about understanding how the movement of one object is observed from the perspective of another moving object. In scenarios where two bodies are moving relative to each other, like a vehicle on a ramp attached to a moving flatcar, analyzing the relationship between their relative velocities and the overall motion is crucial for correctly applying conservation laws.

Conservation of Energy

This concept involves the principle that in a closed, frictionless system, the total mechanical energy (potential plus kinetic) remains constant. In the context of the problem, the gravitational potential energy lost by the vehicle as it rolls down the ramp is converted into the kinetic energies of both the vehicle and the flatcar.

Conservation of Momentum

For an isolated system where no external forces act in a particular direction, the total momentum in that direction is conserved. In this problem, the absence of friction and other horizontal forces ensures that the combined horizontal momentum of the vehicle and the flatcar remains constant, allowing the connection of their individual velocities.
