The allowable shearing stress is 15 ksi in the 1.5 -in.-diameter steel rod $A B$ and 8 ksi in the 1.8 -in.-diameter brass rod $B C .$ Neglecting the effect of stress concentrations, determine the largest torque T that can be applied at $A$

Key Concepts

Torsion of Circular Shafts

This concept involves analyzing how a circular shaft subjected to a torque develops shear stress. The torsion formula ? = T*c/J relates the applied torque (T) to the shear stress (?) through the radius (c) and the polar moment of inertia (J) of the shaft. It is fundamental in determining how far a shaft can be twisted before the material's shear strength is exceeded.

Polar Moment of Inertia

The polar moment of inertia (J) is a geometrical property of a cross-section that indicates its resistance to torsion. For circular shafts, it is calculated using the formula J = (?*d^4)/32, where d is the diameter. This property is crucial in assessing the distribution of shear stress over the cross-section when a torque is applied.

Allowable Shear Stress

Allowable shear stress is the maximum shear stress that a material can safely endure under loading without experiencing failure. In design, ensuring that the stress induced by applied loads is below this limit is vital for maintaining structural integrity and preventing material failure.

Design of Composite Shafts

When a rotating shaft includes segments made of different materials or having different diameters, each section may have its own allowable stress limits. The overall capacity of the shaft is determined by the segment with the lower limit, as it is the most critical point under torsional loading. This concept is essential in the design and analysis of stepped or composite shafts.
