The Arecibo radio telescope has a diameter of 300 m. Assume that it receives electromagnetic wav

step 1 We have a telescope that has a diameter of 300 meters. We're using wavelength of light that is 0

The Arecibo radio telescope has a diameter of 300 m. Assume...

The Arecibo radio telescope has a diameter of $300 \mathrm{m}$. Assume that it receives electromagnetic waves of wavelength $8.0 \mathrm{cm}$ Determine if this radio telescope will see the Andromeda galaxy (a distance of $2.5 \times 10^{6}$ light years away) as a point source of light or an extended object. Take the diameter of Andromeda to be $2.2 \times 10^{5}$ light years.

Key Concepts

Extended vs. Point Source Classification

The classification of an object as extended or point-like depends on whether its angular size exceeds the angular resolution of the observing instrument. If an object's angular size is larger than the resolution limit (set by diffraction or other factors), it can be resolved as an extended object. Conversely, if its angular size is smaller, it will appear as a point source. This concept is used to assess the level of detail that can be discerned by the telescope.

Angular Size

Angular size is the apparent size of an object as seen by an observer and is defined by the ratio of the object's physical size to its distance from the observer. Under the small angle approximation, the angular size can be expressed as the diameter of the object divided by its distance. This concept is essential when comparing the size of an astronomical object to the resolving capability of a telescope to determine if the object will be seen as extended or point-like.

Diffraction Limit

The diffraction limit is the fundamental limit to the performance of an optical system due to the diffraction of light, meaning that even an ideal optical system cannot focus a point source into an infinitely small point. This limit sets the minimum angular separation between two points that can be resolved and is critical when determining whether an object will appear as an extended object or a point source.

Angular Resolution

Angular resolution is the ability of an instrument, such as a telescope, to distinguish between two close objects in the sky. It is generally determined by the wavelength of the observed electromagnetic radiation and the diameter of the telescope's aperture. In a diffraction-limited system, the smallest resolvable angle is often estimated by the formula ?/D, which dictates that a larger aperture or shorter wavelength leads to a finer resolution.
