The boom D F of the jib crane and the column D E have a...

The boom $D F$ of the jib crane and the column $D E$ have a uniform weight of $50 \mathrm{lb} / \mathrm{ft}$. If the supported load is 300 Ib, determine the resultant internal loadings in the crane on cross sections at points $A, B,$ and $C$

Key Concepts

Static Equilibrium

This concept involves analyzing structures or body systems by ensuring that the sum of forces and moments equals zero. In the context of structural analysis, establishing equilibrium is fundamental to determining reaction forces and internal loads within a structure, which is essential for ensuring that the structure can safely support applied loads.

Free-Body Diagram (FBD)

A free-body diagram is a simplified representation of a structure or a segment of it, isolating the body and depicting all external forces and moments acting upon it. FBDs are crucial for visualizing force distributions and are used as the starting point for applying equilibrium equations in structural analysis.

Uniformly Distributed Load (UDL)

A uniformly distributed load is a load that is spread evenly along a structural element such as a beam or column. This type of load is common in structural applications and must be properly integrated or summed over the element’s length to determine its resultant effect, which is then used in calculating reaction forces and internal stresses.

Point Load

A point load is a concentrated force applied at a specific location on a structural element. In analysis, point loads are handled separately from distributed loads, as they can create localized stress concentrations, and are essential for accurate determination of internal forces and moments.

Internal Forces (Shear Force and Bending Moment)

Internal forces refer to the forces and moments that develop within a structure as a response to external loads. Specifically, shear forces represent the internal forces that cause segments of a structural element to slide relative to each other, while bending moments indicate the tendency of a section to rotate about an axis. These concepts are vital for determining the strength and safety of the structure at various cross-sections.
