The car A is ascending a parking-garage ramp in the form of...

The car $A$ is ascending a parking-garage ramp in the form of a cylindrical helix of 24 -ft radius rising 10 ft for each half turn. At the position shown the car has a speed of $15 \mathrm{mi} / \mathrm{hr}$, which is decreasing at the rate of $2 \mathrm{mi} / \mathrm{hr}$ per second. Determine the $r, \theta$ and $z$ -components of the acceleration of the car.

Key Concepts

Cylindrical Coordinate System

This system represents points using a radial distance (r), an angular coordinate (?), and a vertical coordinate (z). It is especially useful for problems involving circular symmetry or helical paths. The unit vectors in this coordinate system change direction with the angle, which is important when computing derivatives such as velocity and acceleration.

Helical Motion

Helical motion is characterized by a constant radial distance and a uniform vertical rise combined with circular motion. In such problems, the path of the object is a helix, and its position can be described using constant r, a linearly increasing ?, and a z-component that changes in proportion to the angular displacement. Understanding this geometry is crucial for decomposing the movement into its coordinate components.

Acceleration Components in Cylindrical Coordinates

Acceleration in cylindrical coordinates is expressed in terms of the changes in r, ?, and z as well as the derivatives of the associated unit vectors. The expression includes radial acceleration, which accounts for changes in the distance from the axis; angular (or tangential) acceleration, which accounts for changes in the speed along the circular path; and vertical acceleration, which is simply the second derivative of the z-coordinate.

Tangential and Normal (Centripetal) Acceleration

In curvilinear motion, acceleration naturally decomposes into tangential (along the path) and normal (pointing toward the center of curvature) components. The tangential component is associated with the time rate of change of the speed (i.e., how fast the object is speeding up or slowing down), while the normal component (often called centripetal acceleration in circular motion) points toward the center of the curve and is related to the square of the speed divided by the radius of curvature.

Unit Conversion

Accurate problem solving in dynamics often requires the conversion of units, particularly when speeds and accelerations are given in different systems such as miles per hour and feet per second. Ensuring consistency across units (for example, converting mph to ft/s) is essential for correct calculation of acceleration components and force analyses.
