The charge is at A in the medium 1 and has an image point at...

The charge is at $A$ in the medium 1 and has an image point at $A^{\prime}$ in the medium $2 .$ The electric field in the medium 1 is due to the actual charge $q$ at $A$ and the image charge $q^{\prime}$ at $A^{\prime} .$ The electric field in 2 is due to a corrected charge $q^{\prime}$ at $A .$ Thus on the boundary between 1 and 2 , $E_{1 n}=\frac{q^{\prime}}{4 \pi \varepsilon_{0} r^{2}} \cos \theta-\frac{q}{4 \pi \varepsilon_{0} r^{2}} \cos \theta$ $E_{2 n}=\frac{-q^{\prime \prime}}{4 \pi \varepsilon_{0} r^{2}} \cos \theta$ $E_{1 t}=\frac{q^{\prime}}{4 \pi \varepsilon_{0} r^{2}} \sin \theta+\frac{q}{4 \pi \varepsilon_{0} r^{2}} \sin \theta$ $E_{2 t}=\frac{q^{\prime \prime}}{4 \pi \varepsilon_{0} r^{2}} \sin \theta$ The boundary conditions are $D_{1 n}=D_{2 n}$ and $E_{1 t}=E_{2 t}$ $\varepsilon q^{\prime \prime}=q-q^{\prime}$ $q^{\prime \prime}=q+q^{\prime}$ So, $q^{\prime \prime}=\frac{2 q}{\varepsilon+1}, q^{\prime}=-\frac{\varepsilon-1}{\varepsilon+1} q$ (a) The surface density of the bound charge on the surface of the dielectric $$ \begin{aligned} \sigma^{\prime} &=P_{2 n}=D_{2 n}-\varepsilon_{0} E_{2 n}=(\varepsilon-1) \varepsilon_{0} E_{2 n} \\ &=-\frac{\varepsilon-1}{\varepsilon+1} \frac{q}{2 \pi r^{2}} \cos \theta=-\frac{\varepsilon-1}{\varepsilon+1} \frac{q l}{2 \pi r^{3}} \end{aligned} $$ (b) Total bound charge is, $-\frac{\varepsilon-1}{\varepsilon+1} q \int_{0} \frac{l}{2 \pi\left(l^{2}+x^{2}\right)^{3 / 2}} 2 \pi x d x=-\frac{\varepsilon-1}{\varepsilon+1} q$

The charge is at $A$ in the medium 1 and has an image point at $A^{\prime}$ in the medium $2 .$ The electric field in the medium 1 is due to the actual charge $q$ at $A$ and the image charge $q^{\prime}$ at $A^{\prime} .$ The electric field in 2 is due to a corrected charge $q^{\prime}$ at $A .$ Thus on the boundary between 1 and 2 ,
$E_{1 n}=\frac{q^{\prime}}{4 \pi \varepsilon_{0} r^{2}} \cos \theta-\frac{q}{4 \pi \varepsilon_{0} r^{2}} \cos \theta$
$E_{2 n}=\frac{-q^{\prime \prime}}{4 \pi \varepsilon_{0} r^{2}} \cos \theta$
$E_{1 t}=\frac{q^{\prime}}{4 \pi \varepsilon_{0} r^{2}} \sin \theta+\frac{q}{4 \pi \varepsilon_{0} r^{2}} \sin \theta$
$E_{2 t}=\frac{q^{\prime \prime}}{4 \pi \varepsilon_{0} r^{2}} \sin \theta$
The boundary conditions are $D_{1 n}=D_{2 n}$ and $E_{1 t}=E_{2 t}$
$\varepsilon q^{\prime \prime}=q-q^{\prime}$
$q^{\prime \prime}=q+q^{\prime}$
So, $q^{\prime \prime}=\frac{2 q}{\varepsilon+1}, q^{\prime}=-\frac{\varepsilon-1}{\varepsilon+1} q$
(a) The surface density of the bound charge on the surface of the dielectric
$$
\begin{aligned}
\sigma^{\prime} &=P_{2 n}=D_{2 n}-\varepsilon_{0} E_{2 n}=(\varepsilon-1) \varepsilon_{0} E_{2 n} \\
&=-\frac{\varepsilon-1}{\varepsilon+1} \frac{q}{2 \pi r^{2}} \cos \theta=-\frac{\varepsilon-1}{\varepsilon+1} \frac{q l}{2 \pi r^{3}}
\end{aligned}
$$
(b) Total bound charge is, $-\frac{\varepsilon-1}{\varepsilon+1} q \int_{0} \frac{l}{2 \pi\left(l^{2}+x^{2}\right)^{3 / 2}} 2 \pi x d x=-\frac{\varepsilon-1}{\varepsilon+1} q$

Key Concepts

Integration of Charge Distributions

Once the local surface charge density is determined, integration over the appropriate surface area is used to compute the total bound charge. This process is essential for ensuring consistency with the overall charge balance and understanding how distributed charges contribute to the global field configuration in the presence of a dielectric.

Dielectric Constant Effects

The dielectric constant, often represented by ?, quantifies a material's ability to reduce the effective electric field within it. It affects the relationship between the electric field, polarization, and electric displacement. Variations in the dielectric constant lead to different scaling factors in the boundary conditions, which in turn influence the magnitude and distribution of both the actual and image charges.

Induced Surface Charge Density

When a dielectric material is polarized, bound charges accumulate at its surface. The distribution of these charges, known as the induced surface charge density, is directly related to the discontinuity in the normal component of the electric displacement field and the degree of polarization. This concept is integral in determining the net effect of the dielectric on nearby electric fields.

Polarization in Dielectrics

Polarization refers to the alignment of dipole moments within a dielectric material when exposed to an external electric field. This results in bound charges at the surfaces and within the volume of the dielectric, which in turn affect the overall electric field. The polarization is typically proportional to the electric field and is related to the dielectric constant of the material.

Boundary Conditions at Dielectric Interfaces

At the interface between two media, the electric fields must satisfy specific continuity conditions. The normal component of the electric displacement field (D) must be continuous in the absence of free surface charges, while the tangential component of the electric field (E) must also remain continuous. These conditions are crucial for accurately determining the fields in both regions and for relating the image and actual charges.

Image Charge Method

This is a mathematical technique used to replace the effect of boundary conditions with fictitious charges (image charges) so that the field equations become simpler to solve. In problems where a charge is located near a boundary between different media, introducing an image charge (or charges) provides a way to satisfy the potential and field conditions on the surfaces without solving the full boundary value problem.
