The cogeneration gas-turbine cycle can be augmented with a heat pump to extract more energy from the turbine exhaust gas, as shown in Fig. P12.178. The heat pump upgrades the energy to be delivered at the $70^{\circ} \mathrm{C}$ line for district heating. In the modified application, the first heat exchanger has exit temperature $T_{6 a}=T_{7 a}=45^{\circ} \mathrm{C}$ and the second one has $T_{6 b}=T_{7 b}=36^{\circ} \mathrm{C} .$ Assume the district heating line has the same exit temperature as before so this arrangement allows for a higher flow rate. Estimate the increase in the district heating load that can be obtained and the necessary work input to the heat pump.

Key Concepts

Waste Heat Recovery

Waste heat recovery involves capturing low-grade heat that would otherwise be lost in industrial processes or power generation systems and repurposing it for useful applications. This process improves overall system efficiency by enabling additional energy recovery and, when combined with devices like heat pumps, allows for temperature upgrading to meet specific end-use requirements.

District Heating

District heating is a centralized heating system that distributes thermal energy through a network of insulated pipes to provide space heating and hot water for residential, commercial, and industrial buildings. It often utilizes heat recovered from industrial processes or cogeneration plants, benefiting from efficient energy conversion and reduced fossil fuel use.

Heat Exchangers

Heat exchangers are devices designed to transfer heat efficiently between two or more fluids without mixing them. They are critical in systems that recover and upgrade waste heat, as they allow energy to be absorbed and then released at a higher temperature, ensuring optimal heat exchange and increased energy utilization.

Heat Pump Operation

A heat pump is a device that transfers thermal energy from a cooler source to a hotter sink by consuming work, effectively upgrading the quality of low-grade heat. In the context of energy systems, it is used to elevate the temperature of waste heat to a level suitable for applications like district heating, thereby enhancing the total heat output.

Cogeneration

Cogeneration refers to the simultaneous production of electricity and useful thermal energy from a single energy source, increasing overall energy efficiency. It involves capturing and utilizing heat that would otherwise be wasted in power generation processes, thereby providing energy for applications such as industrial processes or district heating systems.

Gas-Turbine Cycle

The gas-turbine cycle is a thermodynamic cycle that converts fuel energy into mechanical work via a turbine and then into electricity, often producing high-temperature exhaust gases that carry significant residual energy. This cycle is commonly used in power generation and can be integrated with cogeneration systems for improved efficiency.
