The composite beam is made of steel $(A)$ bonded to brass $(B)$ and has the cross section shown. If it is subjected to a moment of $M=6.5 \mathrm{kN} \cdot \mathrm{m},$ determine the maximum bending stress in the brass and steel. Also, what is the stress in each material at the seam where they are bonded together? $E_{\mathrm{br}}=100 \mathrm{GPa}, E_{\mathrm{st}}=200 \mathrm{GPa}$.

Key Concepts

Composite Beams

Composite beams consist of two or more materials which are bonded together to act as a single structural unit. The analysis of composite beams requires consideration of the different mechanical properties of the constituent materials so that the overall behavior under loads can be determined accurately.

Modular Ratio

The modular ratio is the ratio of the modulus of elasticity of one material to that of another. It is used to convert one material's cross-sectional area into an equivalent area of the other material, which simplifies the analysis of composite sections by making them comparable in stiffness.

Transformed Section Method

The transformed section method is a technique used to analyze composite beams by converting the cross-sectional areas of the constituent materials into equivalent areas of a single material, using the modular ratio. This allows engineers to compute section properties such as the moment of inertia and neutral axis location more easily.

Neutral Axis

The neutral axis is the line in a beam's cross section where the bending stress is zero. In composite beam analysis, locating the neutral axis is important because it determines the stress distribution in both materials, reflecting their different stiffness properties.

Bending Stress Distribution

Bending stress distribution in beams is determined by the moment applied, the distance from the neutral axis, and the beam's moment of inertia. In composite beams, the bending stress varies across the different materials, and is evaluated by combining the transformed section properties with the flexural formula.

Strain Compatibility

Strain compatibility refers to the concept that bonded materials in a composite beam must experience the same strain at the interface. This fundamental assumption allows for the derivation of relationships between the stresses in each material and is crucial when analyzing the stress transfer across the bonded seam.
