Name: Problem 89, Chapter 7: Machines and mechanisms : Applied Kinematic Analysis
Uploaded: 2021-10-21T14:49:17-08:00
Duration: 3 min 6 s
Channel: Manish Jain
Description: The crank of the power hacksaw shown in Figure P7.32 is driven clockwise at a constant rate of 90 rpm . Use the Working Model software to create a simulation and plot a linear acceleration curve of the blade as a function of time.

The crank of the power hacksaw shown in Figure P7.32 is driven clockwise at a constant rate of 90 rpm . Use the Working Model software to create a simulation and plot a linear acceleration curve of the blade as a function of time.

Key Concepts

Rotational Kinematics

This concept involves understanding the properties of rotating bodies, such as angular velocity, period, and the conversion between angular and linear quantities. It is particularly important when analyzing systems where constant rotational speed leads to varying linear accelerations in components of the mechanism.

Conversion of Rotational to Linear Motion

This concept deals with the mechanical linkages that transform rotational motion into linear, often reciprocating, motion. In mechanisms like a power hacksaw, the rotational motion of a crank is converted into the back-and-forth motion of the blade, necessitating analysis of how the geometry and configuration affect the resultant linear acceleration.

Acceleration Components in Curved Motion

Even in scenarios with constant angular velocity, a point on a rotating body experiences centripetal acceleration because its velocity direction continuously changes. Understanding these acceleration components is crucial when the rotation is converted into linear motion, as different parts of the mechanism may experience varying acceleration profiles.

Kinematic Simulation and Analysis

This concept involves the use of simulation tools to model the behavior of mechanical systems. It covers setting up the system with correct parameters, running the simulation to capture time-dependent data, and plotting graphs—such as the linear acceleration curve—to gain insights into the dynamic performance of the mechanism.
