The current in an R L circuit drops from 1.0 A to 10 mA in the first second following removal

step 1 High in the given problem initial current the maximum current in a series RL circuit is given as

The current in an R L circuit drops from 1.0 A to 10 mA in...

The current in an $R L$ circuit drops from $1.0 \mathrm{~A}$ to $10 \mathrm{~mA}$ in the first second following removal of the battery from the circuit. If $L$ is $10 \mathrm{H}$, find the resistance $R$ in the circuit.

Key Concepts

RL Circuit

An RL circuit is a network composed of a resistor and an inductor. The inductor stores energy in a magnetic field and resists changes in current, leading to unique transient behaviors when the circuit conditions change, such as when a battery is removed. This type of circuit is a foundational example in the study of circuits, particularly in understanding energy storage and dissipation.

Transient Response

The transient response refers to the behavior of a circuit immediately after a sudden change, such as a switch being opened or closed. In an RL circuit, after the removal of the power supply, the current does not drop instantly but decays over time. Understanding transient response is crucial for predicting how circuits stabilize after disturbances before reaching a steady state.

Time Constant

The time constant, defined as ? = L/R in an RL circuit, is a measure of the speed at which the transient response occurs. It indicates the time it takes for the current to decrease to about 37% of its initial value. The time constant is fundamental in assessing the dynamic behavior of circuits with inductive components.

Exponential Decay

Exponential decay describes the process in which a quantity decreases at a rate proportional to its current value. In the context of an RL circuit, the current decays exponentially over time following the relationship I(t) = I0 e^(?t/?). This concept is widely used to model the decrease of current in transient circuits and aids in calculating circuit parameters such as resistance or inductance.
